Marantz PM6007 - Specifications

Specifications
0
RMS Power output (20 Hz – 20 kHz simultaneous drive of both
channels) :
45 W x 2 (8 Ω/ohms load)
60 W x 2 (4 Ω/ohms load)
0
Total harmonic distortion (20 Hz – 20 kHz simultaneous drive of
both channels, 8 Ω/ohms load) :
0.08 %
0
Output band width (8 Ω/ohms load, 0.06 %) : 10 Hz – 50 kHz
0
Frequency response (CD, 1 W, 8 Ω/ohms load) : 10 Hz – 70 kHz +0 dB, –1 dB
0
Damping factor (8 Ω/ohms load, 40 Hz – 20 kHz) : 100
0
Input sensitivity/Input impedance
PHONO (MM) :
2.2 mV/47 kΩ/kohms
CD, TUNER, NETWORK, RECORDER :
200 mV/20 kΩ/kohms
0
Output voltage
SUBWOOFER OUT :
2.8 V (200 mV input, Volume MAX)
0
Maximum allowable PHONO input level (1 kHz) MM : 100 mV
0
RIAA deviation (20 Hz – 20 kHz) : ±1.0 dB
0
S/N (IHF-A, 8 Ω/ohms load)
PHONO (MM) :
83 dB (5 mV input, 1 W output)
CD, TUNER, NETWORK, RECORDER :
102 dB (2 V input, Rated output)
0
Headphone output: 50 mW/32 Ω/ohms
