Marantz PM6007 User Manual

Inserting the batteries
1
Remove the rear lid in the direction of the arrow and
remove it.
.
2
Insert two batteries correctly into the battery
compartment as indicated.
.
Batteries
3
Put the rear lid back on.
NOTE
0
To prevent damage or leakage of battery fluid:
0
Do not use a new battery together with an old one.
0
Do not use two different types of batteries.
0
Remove the batteries from the remote control unit if it will not be in use for long
periods.
0
If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
Approx. 23 ft/7 m
30° 30°
Contents
Connections Playback Settings Tips Appendix
5
Front panel Rear panel
Remote control
unit
Index

Marantz PM6007 Specifications

General

Frequency Response	10 Hz - 70 kHz
Dimensions	440 x 105 x 370 mm
Weight	7.8 kg
Channels	2
Damping Factor	100
Signal to Noise Ratio High level	102 dB
DAC chip	AK4490
Total Harmonic Distortion (20Hz-20kHz, 45W/8Ω)	0.02%
Signal-to-Noise Ratio MM	83 dB
Input Impedance MM	47 kΩ
Power Consumption	155 W
Standby Power Consumption	0.3 W
Dimensions (W x H x D)	440 x 105 x 370 mm
Power Output	45 W
Total Harmonic Distortion	0.02%
Input Sensitivity	200mV
Integrated Amplifier Power Output	45W per channel (8Ω)
Input Sensitivity MM	2.5mV
Signal to Noise Ratio MM/MC	83 dB (MM)
Input Sensitivity High level	200mV
Digital Inputs	1 Coaxial
Phono Input	Yes (MM)
Power Output (8Ω, 20Hz-20kHz, 0.02% THD)	45 W
Signal-to-Noise Ratio MC	64dB
Input Impedance MC	100Ω
