NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
58
P.W.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
POS. NO.
P101 C604 1340100865080 1340100865080 ELECT. CAP. RA2-63V221MH5#8-S1
P101 C605 1340100865080 1340100865080 ELECT. CAP. RA2-63V221MH5#8-S1
P101 C606 1340100865080 1340100865080 ELECT. CAP. RA2-63V221MH5#8-S1
P101 C607 1330500444000 1330500444000 FILM CAP. DTG-100VDC-681J-TP
P101
C608
1330500444000
1330500444000
FILM CAP
DTG 100VDC 681J TP
P101
C608
1330500444000
1330500444000
FILM
CAP
.
DTG
-
100VDC
-
681J
-
TP
P101 C609 1340100465000 1340100465000 ELECT. CAP. RA2-25V221MG3#8-T2
P101 C610 1340100465000 1340100465000 ELECT. CAP. RA2-25V221MG3#8-T2
P101 C611
/
N1B 1330500424040 1330500424040 FILM CAP. DAMG-630VDC-101J-TP
P101 C611
/
N1SG 1330500424040 1330500424040 FILM CAP. DAMG-630VDC-101J-TP
P101 C612
/
N1B 1330500424040 1330500424040 FILM CAP. DAMG-630VDC-101J-TP
P101 C612
/
N1SG 1330500424040 1330500424040 FILM CAP. DAMG-630VDC-101J-TP
P101 C613 1340500044050 1340500044050 ELECT. CAP. 22 UF M 25V ARS
P101 C614 1340500044050 1340500044050 ELECT. CAP. 22 UF M 25V ARS
P101
C615
1340500044050
1340500044050
ELECT CAP
22 UF M 25V ARS
P101
C615
1340500044050
1340500044050
ELECT
.
CAP
.
22
UF
M
25V
ARS
P101 C616 1340500044050 1340500044050 ELECT. CAP. 22 UF M 25V ARS
P101 C811 1340500024090 1340500024090 ELECT. CAP. 10 UF 35V ARS
P101 C812 1340500024090 1340500024090 ELECT. CAP. 10 UF 35V ARS
P101 C813 1340500114030 1340500114030 ELECT. CAP. 220UF M 25 V ARA
P101 C814 1340500114030 1340500114030 ELECT. CAP. 220UF M 25 V ARA
P101 C815 1340500114030 1340500114030 ELECT. CAP. 220UF M 25 V ARA
P101 C816 1340500114030 1340500114030 ELECT. CAP. 220UF M 25 V ARA
P101 C821 1340100595060 1340100595060 ELECT. CAP. RA2-35V221MH3#8-T2
P101 C901 1340100665040 1340100665040 ELECT. CAP. RA2-50V010ME3E#8-T2
P101 C902 1340100705030 1340100705030 ELECT. CAP. RA2-50V100ME3E#8-T2
P101 D281 ns
p
00D2760401905 DIODE 1SS133T77
P101 D282 ns
p
00D2760401905 DIODE 1SS133T77
P101 D283 ns
p
00D2760401905 DIODE 1SS133T77
P101 D301 ns
p
00D2760401905 DIODE 1SS133T77
P101 D391 ns
p
00D2760401905 DIODE 1SS133T77
P101 D501 ns
p
00D2760401905 DIODE 1SS133T77
P101 D502 ns
p
00D2760401905 DIODE 1SS133T77
P101 D503 ns
p
00D2760401905 DIODE 1SS133T77
P101 D504 ns
p
00D2760401905 DIODE 1SS133T77
P101 D601 ns
p
00D2760401905 DIODE 1SS133T77
P101 D602 ns
p
00D2760401905 DIODE 1SS133T77
P101 D603 ns
p
00D2760401905 DIODE 1SS133T77
P101 D604 ns
p
00D2760401905 DIODE 1SS133T77
P101 D605 ns
p
00D2760401905 DIODE 1SS133T77
P101 D606 ns
p
00D2760401905 DIODE 1SS133T77
P101 D607 ns
p
00D2760401905 DIODE 1SS133T77
P101 D608 ns
p
00D2760401905 DIODE 1SS133T77
P101
D609
nsp
00D2760401905
DIODE
1SS133T77
P101
D609
nsp
00D2760401905
DIODE
1SS133T77
P101 D610 ns
p
00D2760401905 DIODE 1SS133T77
P101 D611 ns
p
00D2760401905 DIODE 1SS133T77
P101 D612 ns
p
00D2760401905 DIODE 1SS133T77
P101 D613 ns
p
00D2760401905 DIODE 1SS133T77
P101 D614 ns
p
00D2760401905 DIODE 1SS133T77
P101 D615 ns
p
00D2760401905 DIODE 1SS133T77
P101 D616 ns
p
00D2760401905 DIODE 1SS133T77
P101 D811 ns
p
00D2760401905 DIODE 1SS133T77
P1
0
1D
8
12 n
sp
00
D27
60
4
0
1
905
DI
O
DE 1
SS
1
33
T77
0
8
sp
00 60 0 905
O
SS 33
P101 D813 ns
p
00D2760645910 DIODE MTZJ20A T77
P101 D814 ns
p
00D2760645910 DIODE MTZJ20A T77
P101 D911 ns
p
00D2760401905 DIODE 1SS133T77
P101 D912 ns
p
00D2760401905 DIODE 1SS133T77
P101 J301 643810029001S 643810029001S TERMINAL CINCH JACK 2P AU MSP-242V3-12 GILT LF
P101 J302 643810028008S 643810028008S TERMINAL CINCH JACK 4P AU MSP-244V4-17 GILT LF
P101 J303 643810028008S 643810028008S TERMINAL CINCH JACK 4P AU MSP-244V4-17 GILT LF
P101 J304 643810028008S 643810028008S TERMINAL CINCH JACK 4P AU MSP-244V4-17 GILT LF
P101 L281 00D2140208003 00D2140208003 RELAY RELAY
(
NA24W-K
)
P101 L282 00D2140208003 00D2140208003 RELAY RELAY
(
NA24W-K
)
P101 L283 00D2140208003 00D2140208003 RELAY RELAY
(
NA24W-K
)
P101 L284 00D2140208003 00D2140208003 RELAY RELAY
(
NA24W-K
)
P101 L301 00D2140208003 00D2140208003 RELAY RELAY
(
NA24W-K
)
P101 L912 1190100014090 1190100014090 FERRITE CORE BL02RN2R1N1A FERRITE BEAD
P101 Q281 00D2690206908 00D2690206908 TRS. KRC102M-AT/P
(
10K-10K
)
P101 Q283 00D2690206908 00D2690206908 TRS. KRC102M-AT/P
(
10K-10K
)
