Marantz PM8003 - Page 60

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
70
P.W.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
POS. NO.
P851 D861 2030500013020 2030500013020 DIODE ! 1D3 1A/200V
P851 D862 2030500013020 2030500013020 DIODE ! 1D3 1A/200V
P851 D863 2030500013020 2030500013020 DIODE ! 1D3 1A/200V
P851 D864 2030500013020 2030500013020 DIODE ! 1D3 1A/200V
P851
D865
2030500013020
2030500013020
DIODE
! 1D3 1A/200V
P851
D865
2030500013020
2030500013020
DIODE
!
1D3
1A/200V
P851 D866 2030500013020 2030500013020 DIODE ! 1D3 1A/200V
P851 F851 F N ns
p
0520100180090 FUSE # 021806.3MXP
(
FUSE 6.3A 250V
)
P851 F851
/
N1B 0520100150000 0520100150000 FUSE # 02183.15MXP
P851 F851
/
N1SG 0520100150000 0520100150000 FUSE # 02183.15MXP
P851 F851
/
U1B ns
p
0520100180090 FUSE # 021806.3MXP
(
FUSE 6.3A 250V
)
P851 F852 F N ns
p
0520100150000 FUSE # 02183.15MXP
P851 G851 00MBF68400010 00MBF68400010 CAP.COMP. ! 0.68UF/4.7OHM
P851 J860 F N ns
p
6410500020060 TERMINAL ! M7039-A AC OUTLET
P851
J863
643810027005M
643810027005M
TERMINAL
CINCH JACK 2P ORG YKC21-3641N
P851
J863
643810027005M
643810027005M
TERMINAL
CINCH
JACK
2P
ORG
YKC21-3641N
P851 L851 F N ns
p
1010100050048 TRANSF. # POWER TRANSFORMER FOR 110V/100V
P851 L851
/
N1B 1013100020028 1013100020028 TRANSF. # STANDBY TRANSFORMER FOR 230V
P851 L851
/
N1SG 1013100020028 1013100020028 TRANSF. # STANDBY TRANSFORMER FOR 230V
P851 L851
/
U1B ns
p
102010001005M TRANSF. # STANDBY TRANSFORMER FOR 120V
P851 L852 682010006001S 682010006001S RELAY # FTR-H2AK009T
P851 L853 1190100014090 1190100014090 FERRITE CORE BL02RN2R1N1A FERRITE BEAD
P851 L854 1190100014090 1190100014090 FERRITE CORE BL02RN2R1N1A FERRITE BEAD
P851 L855 1190100014090 1190100014090 FERRITE CORE BL02RN2R1N1A FERRITE BEAD
P851 Q851 2130500010020 2130500010020 TRS. KTC3199 RANK=Y
P851 Q852 231010022009S 231010022009S IC ! PQ050ES1MXPQ
P851 Q853 2310100020050 2310100020050 IC ! NJM7805FA +5V
P851 Q854 2110500020090 2110500020090 TRS. KTA1268 RANK=GR
P851 Q855 00D2690204900 00D2690204900 TRS. KRA102M-AT/P
(
10K-10K
)
P851 R851 ns
p
1210100134050 RES. CFPS1/4CMHTA220J
P851 R852 ns
p
00D2412400911 RES. RD14B2E472JT
(
5
)
P851 R853 ns
p
00D2412400911 RES. RD14B2E472JT
(
5
)
P851 R854 ns
p
00D2412403934 RES. RD14B2E104JT
(
5
)
P851 R855 1210500010040 1210500010040 RES. ! CFPB1/2CL12.5A1R0J
P851 R856 1210500010040 1210500010040 RES. ! CFPB1/2CL12.5A1R0J
P851 R858 ns
p
00D2412403934 RES. RD14B2E104JT
(
5
)
P851 R859 ns
p
00D2412398955 RES. RD14B2E102JT
(
5
)
P851 R860 ns
p
00D2412398955 RES. RD14B2E102JT
(
5
)
P851 R861 ns
p
00D2412400995 RES. RD14B2E103JT
(
5
)
P851 R862 ns
p
00D2412395945 RES. RD14B2E470JT
(
5
)
POWER SW PWB
(
P891
)
(
00MWA24AJ206-
)
P891 C891 1320500030000 1320500030000 CER. CAP. # DE0910-1B 471 K - KX
P891 S891 665010008002D 665010008002D SW # POWER SWITCH
(
TV-5
)
U COM PWB(PU01) (00MWA24AJ201 )
U
-
COM
PWB(PU01)
(00MWA24AJ201
-
)
PU01 CU31 1340101314080 1340101314080 ELECT. CAP. RC2-25V101MG1#-T2
PU01 CU33 1340101314080 1340101314080 ELECT. CAP. RC2-25V101MG1#-T2
PU01 CU73 1340101184050 1340101184050 ELECT. CAP. RC2-10V221MG1#-T2
PU01 CU82 1340101314080 1340101314080 ELECT. CAP. RC2-25V101MG1#-T2
PU01 DU71 ns
p
00D2760401905 DIODE 1SS133T77
PU01 DU81 2030500013020 2030500013020 DIODE 1D3 1A/200V
PU01 LU31 1190100014090 1190100014090 FERRITE CORE BL02RN2R1N1A FERRITE BEAD
PU01 LU32 1190100014090 1190100014090 FERRITE CORE BL02RN2R1N1A FERRITE BEAD
P
U0
1
QU0
1 24
39
1
000
1
6008
24
39
1
000
1
6008
U
-PR
O
TMP
86
FH47
UG
U0
QU0
39 000 6008
39 000 6008
UO
86 UG
PU01 00M25AJ499A00 00M25AJ499A00 SOFTWARE PM8003 SOFTWARE FOR QU01 VER.1
PU01 QU02 2469100015000 2469100015000 IC AT24C08AN-10SU-2.7 EEPROM
PU01 QU03 2350100024030 2350100024030 IC PST600D-2 RESET IC
PU01 QU04 00D2690204900 00D2690204900 TRS. KRA102M-AT/P
(
10K-10K
)
PU01 QU05 00D2690204900 00D2690204900 TRS. KRA102M-AT/P
(
10K-10K
)
PU01 QU10 00D2690204900 00D2690204900 TRS. KRA102M-AT/P
(
10K-10K
)
PU01 QU11 00D2690204900 00D2690204900 TRS. KRA102M-AT/P
(
10K-10K
)
PU01 QU12 00D2690204900 00D2690204900 TRS. KRA102M-AT/P
(
10K-10K
)
PU01 QU41 2130500010020 2130500010020 TRS. KTC3199 RANK=Y
PU01 QU42 00D2690204900 00D2690204900 TRS. KRA102M-AT/P
(
10K-10K
)
PU01 QU45 2130500010020 2130500010020 TRS. KTC3199 RANK=Y
PU01 QU46 00D2690204900 00D2690204900 TRS. KRA102M-AT/P
(
10K-10K
)
PU01 QU72 00D2690204900 00D2690204900 TRS. KRA102M-AT/P
(
10K-10K
)
PU01 QU73 00D2690204900 00D2690204900 TRS. KRA102M-AT/P
(
10K-10K
)
PU01 QU74 00D2690204900 00D2690204900 TRS. KRA102M-AT/P
(
10K-10K
)
PU01 QU75 2130500010020 2130500010020 TRS. KTC3199 RANK=Y
