Marantz SR4001 - Page 35

P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
1
/
L1G ns
p
00M27AW154020 KNOB MASTER KNOB
(
GOLD
)
HGK1A089ZA
1
/
N1B 00M27AW154010 00M27AW154010 KNOB MASTER KNOB
(
BLACK
)
HGK1A089YA
1
/
N1G 00M27AW154020 00M27AW154020 KNOB MASTER KNOB
(
GOLD
)
HGK1A089ZA
1
/
N1S 00M27AW154030 00M27AW154030 KNOB MASTER KNOB
(
SILVER
)
HGK1A089XA
1
/
U1B ns
p
00M27AW154010 KNOB MASTER KNOB
(
BLACK
)
HGK1A089YA
2
/
L1G ns
p
00M03CW248110 PANEL FRONT AL PANEL GOLD CKM2A134MC24
2
/
N1B 00M03CW248010 00M03CW248010 PANEL FRONT AL PANEL BLACK CKM2A134MC23
2
/
N1G 00M03CW248110 00M03CW248110 PANEL FRONT AL PANEL GOLD CKM2A134MC24
2
/
N1S 00M03CW248210 00M03CW248210 PANEL FRONT AL PANEL SILVER CKM2A134MC40
2
/
U1B ns
p
00M03CW248020 PANEL FRONT AL PANEL BLACK CKM2A134LC23
3 00M03CW158010 00M03CW158010 WINDOW FIP WINDOW CGU2A346X
4
/
L1G ns
p
00M15CW105110 CHASSIS FRONT MOLD CHASSIS GOLD CGW2A382RFZD4
4
/
N1B 00M15CW105010 00M15CW105010 CHASSIS FRONT MOLD CHASSIS BLACK CGW2A382R4ZK92
4
/
N1G 00M15CW105110 00M15CW105110 CHASSIS FRONT MOLD CHASSIS GOLD CGW2A382RFZD4
4
/
N1S 00M15CW105210 00M15CW105210 CHASSIS FRONT MOLD CHASSIS SILVER CGW2A382R6ZG13
4
/
U1B ns
p
00M15CW105010 CHASSIS FRONT MOLD CHASSIS BLACK CGW2A382R4ZK92
5
/
L1G ns
p
00M07BW270120 BUTTON BUTTON L
(
GOLD
)
CBT1A940RFD4
5
/
N1B 00M07BW270020 00M07BW270020 BUTTON BUTTON L
(
BLACK
)
CBT1A940K92
5
/
N1G 00M07BW270120 00M07BW270120 BUTTON BUTTON L
(
GOLD
)
CBT1A940RFD4
5
/
N1S 00M07BW270220 00M07BW270220 BUTTON BUTTON L
(
SILVER
)
CBT1A940R6G13
5
/
U1B ns
p
00M07BW270020 BUTTON BUTTON L
(
BLACK
)
CBT1A940K92
6
/
L1G ns
p
00M07BW270110 BUTTON CURSOR BUTTON
(
GOLD
)
CBT1A939RFZD4
6
/
N1B 00M07BW270010 00M07BW270010 BUTTON CURSOR BUTTON
(
BLACK
)
CBT1A939ZK92
6
/
N1G 00M07BW270110 00M07BW270110 BUTTON CURSOR BUTTON
(
GOLD
)
CBT1A939RFZD4
6
/
N1S 00M07BW270210 00M07BW270210 BUTTON CURSOR BUTTON
(
SILVER
)
CBT1A939R6ZG13
6
/
U1B ns
p
00M07BW270010 BUTTON CURSOR BUTTON
(
BLACK
)
CBT1A939ZK92
7
/
N1B 00M03CW355010 00M03CW355010 LENS HDMI INDICATOR CGL1A245
7
/
N1G 00M03CW355010 00M03CW355010 LENS HDMI INDICATOR CGL1A245
7
/
N1S 00M03CW355010 00M03CW355010 LENS HDMI INDICATOR CGL1A245
7
/
U1B ns
p
00M03CW355010 LENS HDMI INDICATOR CGL1A245
8
/
L1G ns
p
00M07BW270130 BUTTON BUTTON R
(
GOLD
)
CBT1A941RFD4
8
/
N1B 00M07BW270030 00M07BW270030 BUTTON BUTTON R
(
BLACK
)
CBT1A941K92
8
/
N1G 00M07BW270130 00M07BW270130 BUTTON BUTTON R
(
GOLD
)
CBT1A941RFD4
8
/
N1S 00M07BW270230 00M07BW270230 BUTTON BUTTON R
(
SILVER
)
CBT1A941R6G13
8
/
U1B ns
p
00M07BW270030 BUTTON BUTTON R
(
BLACK
)
CBT1A941K92
9
/
L1G ns
p
ns
p
PWB ASSY FRONT PWB ASSY COP11884N
9
/
N1B ns
p
ns
p
PWB ASSY FRONT PWB ASSY COP11884N
9
/
N1G ns
p
ns
p
PWB ASSY FRONT PWB ASSY COP11884N
9
/
N1S ns
p
ns
p
PWB ASSY FRONT PWB ASSY COP11884M
9
/
U1B ns
p
ns
p
PWB ASSY FRONT PWB ASSY COP11884U
10 00M11BW056010 00M11BW056010 BUFFER RUBBER CUSHION KHG1A050
11
/
L1G ns
p
00M243W057010 LEG LEG GOLD/BLACK CKL2A042H11
11
/
N1B 00M243W057010 00M243W057010 LEG LEG GOLD/BLACK CKL2A042H11
11
/
N1G 00M243W057010 00M243W057010 LEG LEG GOLD/BLACK CKL2A042H11
11
/
N1S 00M243W057210 00M243W057210 LEG LEG FOR SILVER CKL2A042H46
11
/
U1B ns
p
00M243W057010 LEG LEG GOLD/BLACK CKL2A042H11
12 ns
p
ns
p
CHASSIS BOTTOM CHASSIS CUA3A247
13 ns
p
ns
p
BUFFER CUSIHON SUPPORT CHG1A305
14 ns
p
ns
p
BUFFER CUSHION EVA H=9.5
(
15X20
)
CHG1A104
15 ns
p
ns
p
HEATSINK HEAT SINK CMY1A266
16 ns
p
ns
p
BRACKET BRACKET PWB AG-D8900 CMD1A417
18 ns
p
ns
p
PWB ASSY MAIN PWB ASSY -
19 ns
p
ns
p
PWB ASSY DOWNLOADER CONNEC. PWB ASSY -
20
/
L1G ns
p
90M-AV000410R TUNER TUNER MODULE
(
USA
)
CNVMB014MA08L
20
/
N1B 90M-AV000400R 90M-AV000400R TUNER TUNER MODULE
(
EUR
)
CNVMB114MA18L
20
/
N1G 90M-AV000400R 90M-AV000400R TUNER TUNER MODULE
(
EUR
)
CNVMB114MA18L
20
/
N1S 90M-AV000400R 90M-AV000400R TUNER TUNER MODULE
(
EUR
)
CNVMB114MA18L
20
/
U1B ns
p
90M-AV000410R TUNER TUNER MODULE
(
USA
)
CNVMB014MA08L
21
/
L1G ns
p
ns
p
PANEL REAR PANEL /L CKF4A308Z
21
/
N1B ns
p
ns
p
PANEL REAR PANEL /N CKF1A308Z
21
/
N1G ns
p
ns
p
PANEL REAR PANEL /N CKF1A308Z
21
/
N1S ns
p
ns
p
PANEL REAR PANEL /N CKF1A308Z
21
/
U1B ns
p
ns
p
PANEL REAR PANEL /U CKF2A308Z
22 ns
p
ns
p
TAPE TAPE HEMELON KHS1A032
23
/
L1G ns
p
00M24AW251010 BADGE NEW MZ BADGE CGB1A117
23
/
N1B 00M24AW251010 00M24AW251010 BADGE NEW MZ BADGE CGB1A117
23
/
N1G 00M24AW251010 00M24AW251010 BADGE NEW MZ BADGE CGB1A117
POS. NO.
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
55
