Marantz SR4001 - Page 65

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
85
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
BRIDGE DIODE PWB
B DIODE BN21 ns
p
ns
p
CORD WIRE ASSY CWB1E908070MM
B DIODE D991 90M-HE200250R 90M-HE200250R DIODE ! GBJ1504 HVDGBJ1504
B DIODE J847 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
B DIODE J951 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
DOWNLOADER CONNECTOR PWB
(
CUP11884Z-10
)
DL CON BK87 ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
DL CON BK88 ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
DL CON BN85 ns
p
ns
p
CORD WIRE ASSY CWB2B906100EN
DL CON CN83 ns
p
ns
p
CONN. 7P WAFER CARD CABLE CJP07GB113ZY
FRONT TRANS. PWB
(
CUP11884Z-5
)
F TRANS BN96 ns
p
ns
p
CORD WIRE ASSY CWB1C908140BM
F TRANS C933 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
F TRANS C934 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
F TRANS C935 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
F TRANS C936 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
F TRANS C937 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
F TRANS C938 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
F TRANS C939 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
F TRANS C940 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
F TRANS C941 ns
p
00MOA47605020 ELECT CAP. 47UF 50V CCEA1HH470T
F TRANS C942 ns
p
00MOA47605020 ELECT CAP. 47UF 50V CCEA1HH470T
F TRANS C943 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
F TRANS C944 ns
p
00MOA10705020 ELECT CAP. 100UF 50V CCEA1HH101T
F TRANS C945 ns
p
00MOA47701620 ELECT CAP. 470UF 16V ZF CCEA1CH471T
F TRANS CN14 ns
p
ns
p
CONN. 7P STRAIGHT CJP07GA19ZY
F TRANS CN91 ns
p
ns
p
CONN. 3P STRAIGHT CJP03GA01ZY
F TRANS D981 90M-HD201730R 90M-HD201730R DIODE 1N4003 CVD1N4003ST
F TRANS D982 90M-HD201730R 90M-HD201730R DIODE 1N4003 CVD1N4003ST
F TRANS D983 90M-HD201730R 90M-HD201730R DIODE 1N4003 CVD1N4003ST
F TRANS D984 90M-HD201730R 90M-HD201730R DIODE 1N4003 CVD1N4003ST
F TRANS D985 90M-HD201730R 90M-HD201730R DIODE 1N4003 CVD1N4003ST
F TRANS D986 90M-HD201730R 90M-HD201730R DIODE 1N4003 CVD1N4003ST
F TRANS D987 90M-HD302150R 90M-HD302150R ZENER DIODE 6.8V 1/2W HVDMTZJ6.8BT
F TRANS D988 90M-HD302190R 90M-HD302190R ZENER DIODE 30V 1/2W HVDMTZJ30BT
F TRANS D989 90M-HD201730R 90M-HD201730R DIODE 1N4003 CVD1N4003ST
F TRANS J842 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
F TRANS Q901 00MHT600141B0 00MHT600141B0 TRS. KTA1271Y HVTKTA1271YT
F TRANS R954 90M-NH000080R 90M-NH000080R FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
F TRANS R955 90M-NH000080R 90M-NH000080R FUSE RES. ! 0.47 OHM 1W J KRQ1AJR47H
F TRANS R956 90M-NH000150R 90M-NH000150R FUSE RES. ! 0.15 OHM 1W J KRQ1AJR15H
F TRANS R957 90M-NH000150R 90M-NH000150R FUSE RES. ! 0.15 OHM 1W J KRQ1AJR15H
F TRANS R958 ns
p
ns
p
RES. 3.3 OHM 1/5W J CRD20TJ3R3T
F TRANS R959 ns
p
ns
p
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
F TRANS R960 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100T
F TRANS R961 ns
p
ns
p
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
F TRANS R962 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
F TRANS R963 ns
p
ns
p
RES. 1.2K OHM 1/5W J CRD20TJ122T
FRONT PWB
(
CUP11884Z
)
FRONT BK11 ns
p
ns
p
BRACKET BRACKET FLT CMD1A468
FRONT BK12 ns
p
ns
p
BRACKET BRACKET FLT CMD1A468
FRONT BK84 ns
p
ns
p
TERMINAL PLATE EARTH CMC3A111
FRONT BK85 ns
p
ns
p
TERMINAL PLATE EARTH CMC3A111
FRONT BN14 ns
p
ns
p
CORD WIRE ASSY CWB1B907240EN
FRONT BN41 ns
p
ns
p
CORD WIRE ASSY CWB2B905360EN
FRONT BN43 ns
p
ns
p
CORD WIRE ASSY CWB2B905450EN
FRONT BN86 ns
p
ns
p
CORD WIRE ASSY CWB2B907050BM
FRONT C801 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
FRONT C802 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
FRONT C804 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C805 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
FRONT C806 ns
p
00MOA10705020 ELECT CAP. 100UF 50V CCEA1HH101T
FRONT C807 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
FRONT C809 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
FRONT C810 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
FRONT C811 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
FRONT C812 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
POS. NO.
