Marantz SR4001 - Page 69

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
89
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
H/P PWB
(
CUP11884Z-3
)
H/P C874 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
H/P C875 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
H/P C876 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
H/P CN87 ns
p
ns
p
CONN. 5P STRAIGHT CJP05GA19ZY
H/P J836 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
H/P JK81
/
L1G ns
p
90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z
H/P JK81
/
N1B 90M-YT003160R 90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z
H/P JK81
/
N1G 90M-YT003160R 90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z
H/P JK81
/
N1S 90M-YT004500R 90M-YT004500R TERMINAL JACK HEADPHONE
(
SILVER
)
CJJ2E026Z
H/P JK81
/
U1B ns
p
90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z
H/P JW13 ns
p
ns
p
CORD WIRE ASSY CWE8202110RV
H/P R846 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
H/P R847 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
H/P R881 ns
p
ns
p
RES. 330 OHM 1W CRG1ANJ331H
H/P R882 ns
p
ns
p
RES. 330 OHM 1W CRG1ANJ331H
HDMI PWB
(
CUP11887Z
)
HDMI BK91 ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
HDMI BK92 ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
HDMI BN95 ns
p
ns
p
CORD WIRE ASSY CWB1C906150EN
HDMI C901 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C902 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C903 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C904 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C905 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C906 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C907 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C908 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C909 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C910 ns
p
00MDK98103300 CER. CAP. 0.01UF ZF 1608 HCUS1H103ZF
HDMI C911 ns
p
00MDK98103300 CER. CAP. 0.01UF ZF 1608 HCUS1H103ZF
HDMI C912 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C913 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C914 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C915 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C916 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C917 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C918 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C919 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C920 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C921 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C922 ns
p
00MDD95220300 CER. CAP. 22PF 50V JA CCUS1H220JA
HDMI C923 ns
p
00MDD95220300 CER. CAP. 22PF 50V JA CCUS1H220JA
HDMI C924 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C925 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C926 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C927 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C928 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C929 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C930 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C931 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C932 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C933 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C934 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C935 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C936 ns
p
00MDK98103300 CER. CAP. 0.01UF ZF 1608 HCUS1H103ZF
HDMI C937 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C938 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C939 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C941 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C942 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C944 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C945 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C946 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C947 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C948 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C949 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
