Marantz SR4001 - Page 85

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
105
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
IR FLASH R971
/
U1B ns
p
ns
p
RES. 200 OHM 1/5 W CRD20TJ201T
IR FLASH R972
/
U1B ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
IR FLASH R973
/
U1B ns
p
ns
p
RES. 200 OHM 1/5 W CRD20TJ201T
IR FLASH R974 ns
p
ns
p
RES. 47 OHM 1/5W J CRD20TJ470T
MAIN PWB
(
CUP11888Z
)
MAIN BN20 ns
p
ns
p
CORD WIRE ASSY CWB3FB03280UP
MAIN BN22 ns
p
ns
p
CORD WIRE ASSY CWZSR4001BN22
MAIN BN81 ns
p
ns
p
CORD WIRE ASSY CWB1C902050EN
MAIN BN87 ns
p
ns
p
CORD WIRE ASSY CWZSR4001BN87
MAIN BN90
/
L1G ns
p
ns
p
CORD WIRE ASSY CWB4F232550PU
MAIN BN90
/
N1B ns
p
ns
p
CORD WIRE ASSY CWB4F232550PU
MAIN BN90
/
N1G ns
p
ns
p
CORD WIRE ASSY CWB4F232550PU
MAIN BN90
/
N1S ns
p
ns
p
CORD WIRE ASSY CWB4F232550PU
MAIN BN93 ns
p
ns
p
CORD WIRE ASSY CWB1C902250BM
MAIN C501 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C502 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C503 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C504 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C505 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C506 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C507 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C508 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C509 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C510 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C561 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C562 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C563 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C564 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C565 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C566 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C569 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C570 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C571 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C572 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C573 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C574 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C575 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C580 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C581 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C582 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C583 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C584 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C585 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C586 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C587 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C601 ns
p
ns
p
CER. CAP. 12PF 50V JC CCCT1H120JC
MAIN C602 ns
p
ns
p
CER. CAP. 12PF 50V JC CCCT1H120JC
MAIN C603 ns
p
ns
p
CER. CAP. 12PF 50V JC CCCT1H120JC
MAIN C604 ns
p
ns
p
CER. CAP. 12PF 50V JC CCCT1H120JC
MAIN C605 ns
p
ns
p
CER. CAP. 12PF 50V JC CCCT1H120JC
MAIN C606 ns
p
ns
p
CER. CAP. 33PF 50V JC CCCT1H330JC
MAIN C607 ns
p
ns
p
CER. CAP. 33PF 50V JC CCCT1H330JC
MAIN C608 ns
p
ns
p
CER. CAP. 33PF 50V JC CCCT1H330JC
MAIN C609 ns
p
ns
p
CER. CAP. 33PF 50V JC CCCT1H330JC
MAIN C610 ns
p
ns
p
CER. CAP. 33PF 50V JC CCCT1H330JC
MAIN C631 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
MAIN C632 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
MAIN C633 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
MAIN C634 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
MAIN C635 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
MAIN C636 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
MAIN C637 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
MAIN C638 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
MAIN C639 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
MAIN C640 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
MAIN C681 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C682 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
