Marantz SR4001 - Page 92

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
112
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
MAIN Q684 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q685 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q801 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q802 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q803 90M-HT400490R 90M-HT400490R TRS. 2SD2390 HVT2SD2390
MAIN Q804 90M-HT200440R 90M-HT200440R TRS. 2SB1560 HVT2SB1560
MAIN Q805 90M-HT400490R 90M-HT400490R TRS. 2SD2390 HVT2SD2390
MAIN Q807 90M-HT200440R 90M-HT200440R TRS. 2SB1560 HVT2SB1560
MAIN Q812 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q813 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q814 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q815 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q816 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q817 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q818 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q819 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q820 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q821 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q822 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q823 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q824 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q825 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q858 90M-HT100540R 90M-HT100540R TRS. KTA1360Y HVTKTA1360Y
MAIN Q871 90M-HT100540R 90M-HT100540R TRS. KTA1360Y HVTKTA1360Y
MAIN Q872 90M-HT100540R 90M-HT100540R TRS. KTA1360Y HVTKTA1360Y
MAIN Q874 90M-HT100540R 90M-HT100540R TRS. KTA1360Y HVTKTA1360Y
MAIN Q875 90M-HT100540R 90M-HT100540R TRS. KTA1360Y HVTKTA1360Y
MAIN Q876 90M-HT100540R 90M-HT100540R TRS. KTA1360Y HVTKTA1360Y
MAIN Q877 90M-HT100540R 90M-HT100540R TRS. KTA1360Y HVTKTA1360Y
MAIN Q881 90M-HT300820R 90M-HT300820R TRS. KTC3423Y HVTKTC3423Y
MAIN Q882 90M-HT300820R 90M-HT300820R TRS. KTC3423Y HVTKTC3423Y
MAIN Q883 90M-HT300820R 90M-HT300820R TRS. KTC3423Y HVTKTC3423Y
MAIN Q884 90M-HT300820R 90M-HT300820R TRS. KTC3423Y HVTKTC3423Y
MAIN Q885 90M-HT300820R 90M-HT300820R TRS. KTC3423Y HVTKTC3423Y
MAIN Q886 90M-HT300820R 90M-HT300820R TRS. KTC3423Y HVTKTC3423Y
MAIN Q887 90M-HT300820R 90M-HT300820R TRS. KTC3423Y HVTKTC3423Y
MAIN Q901 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
MAIN Q902 90M-BA001530R 90M-BA001530R TRS. KTC114M HVTKRC114MT
MAIN Q903 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN Q904 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
MAIN Q905 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q906 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
MAIN Q911 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
MAIN Q912 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q913 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q915 90M-BA001450R 90M-BA001450R TRS. KRA107M HVTKRA107MT
MAIN Q916 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q917 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN Q918 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
MAIN Q919 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q920 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q921 90M-BA001450R 90M-BA001450R TRS. KRA107M HVTKRA107MT
MAIN Q925 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q928 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN Q929 90M-HT600030R 90M-HT600030R TRS. KTA1024Y HVTKTA1024YT
MAIN Q960 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN Q961 90M-HT600030R 90M-HT600030R TRS. KTA1024Y HVTKTA1024YT
MAIN Q997 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN Q998 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
MAIN R501 ns
p
ns
p
RES. 43K OHM 1/5W J CRD20TJ433T
MAIN R502 ns
p
ns
p
RES. 43K OHM 1/5W J CRD20TJ433T
MAIN R503 ns
p
ns
p
RES. 43K OHM 1/5W J CRD20TJ433T
MAIN R506 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
MAIN R507 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
MAIN R508 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
MAIN R509 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
MAIN R510 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
