Marantz SR4001 - Page 97

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
117
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
MAIN R971 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153T
MAIN R972 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
MAIN R974 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
MAIN R975 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
MAIN R976 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
MAIN R977 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
MAIN R978 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
MAIN R979 ns
p
ns
p
RES. 39K OHM 1/5W J CRD20TJ393T
MAIN R980 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153T
MAIN R981 ns
p
ns
p
RES. 56 OHM 1/4W J CRD25TJ560T
MAIN R990 ns
p
00MGA05100010 RES. 10 OHM CRG1ANJ100H
MAIN R993 ns
p
00MGA05100010 RES. 10 OHM CRG1ANJ100H
MAIN R994 ns
p
00MGA05100010 RES. 10 OHM CRG1ANJ100H
MAIN R995 ns
p
00MGA05100010 RES. 10 OHM CRG1ANJ100H
MAIN R996 ns
p
00MGA05100010 RES. 10 OHM CRG1ANJ100H
MAIN R997 ns
p
00MGA05100010 RES. 10 OHM CRG1ANJ100H
MAIN R999 ns
p
00MGA05100010 RES. 10 OHM CRG1ANJ100H
MAIN RY94 90M-LY000340R 90M-LY000340R RELAY ! SDT-S-112DMR HSL1A008ZE
MAIN RY95 00MLY20240490 00MLY20240490 RELAY 5GPA-28 DC24 HSL3B013ZE
MAIN RY96 00MLY20240510 00MLY20240510 RELAY OSA-SS-224DM3 HSL4B017ZU
MAIN T902
/
L1G ns
p
90M-TS002090R TRANSF. ! SUB SR5400
(
6400
)
/L1 CLT5I002ZS
MAIN T902
/
N1B 90M-TS001940R 90M-TS001940R TRANSF. ! SUB SR5400
(
6400
)
/N1 CLT5I002ZE
MAIN T902
/
N1G 90M-TS001940R 90M-TS001940R TRANSF. ! SUB SR5400
(
6400
)
/N1 CLT5I002ZE
MAIN T902
/
N1S 90M-TS001940R 90M-TS001940R TRANSF. ! SUB SR5400
(
6400
)
/N1 CLT5I002ZE
MAIN T902
/
U1B ns
p
90M-TS001970R TRANSF. ! SUB SR5400
(
6400
)
/U1 CLT5I002ZU
MAIN TH91 90M-HP000090R 90M-HP000090R VARISTOR POSISTOR ASSY CRTSYPSX06850JD
MAIN TH91 ns
p
ns
p
CONN. 2PIN CJP02GA19ZY CJP02GA19ZY
PUSH SW PWB
(
CUP11884-9
)
P SW C877
/
L1G ns
p
90M-DK100800R CER. CAP. ! DKS471ME KCKDKS471ME
P SW C877
/
N1B 90M-DK100800R 90M-DK100800R CER. CAP. ! DKS471ME KCKDKS471ME
P SW C877
/
N1G 90M-DK100800R 90M-DK100800R CER. CAP. ! DKS471ME KCKDKS471ME
P SW C877
/
N1S 90M-DK100800R 90M-DK100800R CER. CAP. ! DKS471ME KCKDKS471ME
P SW CN88
/
L1G ns
p
ns
p
CONN. 2P WAFER CJP02GA89ZY
P SW CN88
/
N1B ns
p
ns
p
CONN. 2P WAFER CJP02GA89ZY
P SW CN88
/
N1G ns
p
ns
p
CONN. 2P WAFER CJP02GA89ZY
P SW CN88
/
N1S ns
p
ns
p
CONN. 2P WAFER CJP02GA89ZY
P SW SW97
/
L1G ns
p
90M-SP001250R SW ! JPP1197CSA64 KSH1A001ZV
P SW SW97
/
N1B 90M-SP001250R 90M-SP001250R SW ! JPP1197CSA64 KSH1A001ZV
P SW SW97
/
N1G 90M-SP001250R 90M-SP001250R SW ! JPP1197CSA64 KSH1A001ZV
P SW SW97
/
N1S 90M-SP001250R 90M-SP001250R SW ! JPP1197CSA64 KSH1A001ZV
REGULATOR PWB
(
CUP11889Z
)
REG. BK81 ns
p
ns
p
BRACKET BRACKET PWB CMD1A387
REG. BN98 ns
p
ns
p
CORD WIRE ASSY CWB1C911120BM
REG. C858 ns
p
ns
p
FILM CAP. 0.047UF 50V J HCQI1H473JZT
REG. C859 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
REG. C860 90M-EA001160R 90M-EA001160R ELECT CAP. 12000UF 16V CCEA1CKL5123E
REG. C861 ns
p
ns
p
FILM CAP. 0.047UF 50V J HCQI1H473JZT
REG. C862 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
REG. C863 90M-EA000990R 90M-EA000990R ELECT CAP. 4700UF 16V CCEA1CH472E
REG. C864 ns
p
90M-OA000160R ELECT CAP. 3300UF/35V CCEA1VH332E
REG. C865 ns
p
00MOA22803520 ELECT CAP. 2200UF 35V CCEA1VH222E
REG. C866 ns
p
ns
p
FILM CAP. 0.047UF 50V J HCQI1H473JZT
REG. C867 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
REG. C871 ns
p
ns
p
CER. CAP. 0.043UF 50V Z CCFT1H473ZF
REG. C872 ns
p
ns
p
CER. CAP. 0.043UF 50V Z CCFT1H473ZF
REG. C873 ns
p
ns
p
CER. CAP. 0.043UF 50V Z CCFT1H473ZF
REG. CN96 ns
p
ns
p
CONN. 8P STRAIGHT CJP08GA01ZY
REG. D861 90M-HD201750R 90M-HD201750R DIODE 1N4003 CVD1N4003SRT
REG. D862 90M-HD201750R 90M-HD201750R DIODE 1N4003 CVD1N4003SRT
REG. D863 90M-HD201750R 90M-HD201750R DIODE 1N4003 CVD1N4003SRT
REG. IC85 90M-HC300750R 90M-HC300750R IC KIA378R05PI HVIKIA378R05PI
REG. IC86 00MHC3891299F 00MHC3891299F IC KIA7812API HVIKIA7812API
REG. IC87 00MHC3991209F 00MHC3991209F IC KIA7912PI HVIKIA7912PI
REG. J801 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG. J802 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG. J803 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
REG. J804 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
