4 VIDEO SETUP
Video settings are made as follows.
1.
Select “4. VIDEO SETUP” from the MAIN
MENU with the 3/4 cursor buttons and press
the ENTER button.
4.VIDEO SETUP
VIDEO CONVERT
TV-AUTO :DISABLE
OSD INFO :ENABLE
COMPONENT I/P:DISABLE
HDMI OUT RES :THROUGH
RETURN NEXT EXIT
2.
Select the desired menu with the 3/4 cursor
buttons and press the ENTER button.
•
VIDEO CONVERT
This unit is equipped to convert video signals for
monitor output.
This section explains how to set up conversion for
each type of video input.
1.
Select “4. VIDEO SETUP” from the MAIN
MENU with the 3 / 4 cursor buttons and press
the ENTER button.
2.
Select “VIDEO CONVERT” with the 3 / 4 cursor
buttons and press the ENTER button.
VIDEO CONVERT
TV : ANA&HDMI
DVD : ANA&HDMI
VCR : ANA&HDMI
DSS : ANA&HDMI
AUX1 : ANA&HDMI
TAPE : ANA&HDMI
CD/R : ANA&HDMI
AUX2 : ANA&HDMI
RETURN BACK EXIT
3.
Select “FUNCTION” with the 3 / 4 cursor
buttons and set the video conversion mode
with the 1 / 2 cursor buttons
ANA&HDMI:
This mode both up-converts and down-converts
analog video signals (Composite Video, S-Video,
Component Video). Furthermore, it up-converts
from analog video signal to HDMI. (It cannot down-
convert from HDMI digital video signals to analog
video signals.)
ANA ONLY:
This mode both up-converts and down-converts
analog video signals (Composite Video, S-Video,
Component Video). It does not up-convert to
HDMI.
OFF:
This mode turns off all conversion features.
Note:
• For details on video convert feature, see page 46.
•
TV-AUTO
Select the TV AUTO ON/OFF function to ENABLE
or DISABLE with the 1 or 2 cursor buttons. (refer
to page 45)
•
OSD INFO
Select the OSD information function to “ENABLE”
or “DISABLE” with the 1 or 2 cursor buttons.
If you select “ENABLE”, this unit will display the
status of the feature (Volume up/down, input
select, etc..) on the monitor. If you do not desire
this information, select “DISABLE”.
Note:
• OSD information is not output to Monitor Output
of HDMI and Component Video. However, OSD
information is output if the Video Convert function
is used to output Video or S-Video video signals to
Monitor Out of HDMI and Component Video.
For details, refer to“VIDEO CONVERT”on page 46.
•
COMPONENT I/P
Set whether or not to convert 480i signals to 480p
signals when outputting the analog video input
signal input from the VIDEO terminals, S-VIDEO
terminals, or COMPONENT terminals.
Select “ENABLE” or “DISABLE.”
DISABLE: Do not convert
ENABLE: Convert
Note:
This setting is enabled only when VIDEO CONVERT
is set to other than OFF.
•
HDMI OUT RES
Selects the resolution of the video signal output
from the HDMI terminal of this unit.
Select from the following using the 1 or 2 cursor
buttons.
AUTO ↔ THROUGH ↔ 480/576p ↔ 720p ↔
1080i ↔ 1080p ↔ AUTO
