Surround Mode Input Signal Decoding
Output Channel Front information display
L/R C
SL
SR
SBL
SBR
SubW Signal format indicators Channel status
SOURCE DIRECT
PURE DIRECT
DTS (5.1ch) DTS 5.1
OOO-O dts L, C, R, SL, SR, LFE
DTS-HD (2ch) DTS-HD
O---- dts-HD MSTR/HIRES L, R
DTS-HD (5.1ch) DTS-HD
OOO-O dts-HD MSTR/HIRES L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-HD (6.1ch) DTS-HD
OOOOO dts-HD MSTR/HIRES L, C, R, SL, SR, S, LFE (,ex1,ex2)
DTS-HD (7.1ch) DTS-HD
OOOOO dts-HD MSTR/HIRES
L, C, R, SL, SR, SBL, SBR, LFE
(,ex1,ex2)
Multi Ch-PCM Multi Ch-PCM
OOO-O PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 96kHz Multi Ch-PCM 96kHz
OOO-O PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) SA-CD (5.1ch)
OOO-O DSD L, C, R, SL, SR, LFE
SA-CD (2ch) SA-CD (Stereo) O- - - O DSD L, R
PCM (Audio) PCM (Stereo) O---- PCM L, R
PCM 96kHz PCM (Stereo 96kHz) O---- PCM L, R
HDCD HDCD O---- PCM, HDCD L, R
Analog Stereo O---- ANALOG -
7.1ch input Multi Ch OOOOO ANALOG -
EX/ES Dolby Surr.EX Dolby Digital EX
OOOOO
2
DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital EX
OOOOO
2
DIGITAL L, C, R, SL, SR, LFE
Dolby Digital Plus (5.1ch) DolbyDigital + +EX
OOOOO
2
DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby TrueHD (5.1ch) DolbyTrueHD +EX
OOOOO
2
TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-ES DTS-ES
OOOOO dts, ES L, C, R, SL, SR, S, LFE
DTS (5.1ch) DTS-ES OOOOO dts L, C, R, SL, SR, LFE
DTS-HD (5.1) DTS-HD + NEO6 OOOOO dts-HD MSTR/HIRES L, C, R, SL, SR, LFE (,ex1,ex2)
Multi-PCM
Multi Ch-P C M + D o l b y
Digital EX
OOOOO PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch)
SA -CD (5 .1c h) + Dolb y
Digital EX
OOOOO DSD L, C, R, SL, SR, LFE
DOLBY
(PL
II
x movie)
(PL
II
x music)
(PL
II
x game)
Dolby Surr.EX Dolby Digital EX
OOO-O
2
DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1
OOO-O
2
DIGITAL L, C, R, SL, SR, LFE
Dolby D (5.1ch) Dolby Digital 5.1 + PL
II
x
OOOOO
2
DIGITAL L, C, R, SL, SR, LFE
Dolby D (2ch) Pro Logic
II
x
OOOOO
2
DIGITAL L, R
Dolby D (2ch Surr) Pro Logic
II
x
OOOOO
2
DIGITAL L, R, S
Dolby Digital Plus (2ch) Pro Logic
II
x
OOOOO
2
DIGITAL PLUS L, R
Dolby Digital Plus (5.1ch) DolbyDigital +
OOO-O
2
DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby Digital Plus (5.1ch) Dolby Digital Plus + PL
II
x
OOOOO
2
DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby TrueHD (2ch) Pro Logic
II
x
OOOOO
2
TrueHD L, R
Dolby TrueHD (5.1ch) DolbyTrueHD + PL
II
x
OOOOO
2
TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
Dolby TrueHD (5.1ch) DolbyTrueHD
OOO-O
2
TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-HD (2ch) DTS-HD
OOOOO
2
TrueHD L, R
Multi Ch-PCM Multi Ch-PCM + PL
II
x
OOOOO PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) SA-CD (5.1ch) + PL
II
x OOOOO DSD L, C, R, SL, SR, LFE
SA-CD (2ch) Pro Logic
II
x OOOOO DSD L, R
PCM (Audio) Pro Logic
II
x OOOOO PCM L, R
HDCD Pro Logic
II
x OOOOO PCM, HDCD L, R
Analog Pro Logic
II
x OOOOO ANALOG -
DTS
(Neo:6 Cinema)
(Neo:6 Music)
DTS-ES DTS 5.1
OOO-O dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS-96/24
OOO-O dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1 OOO-O dts L, C, R, SL, SR, LFE
DTS-HD (2ch) Neo:6 OOOOO dts-HD MSTR/HIRES L, R
DTS-HD (5.1ch) DTS-HD OOO-O dts-HD MSTR/HIRES L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-HD (6.1ch) DTS-HD OOOOO dts-HD MSTR/HIRES L, C, R, SL, SR, S, LFE (,ex1,ex2)
DTS-HD (7.1ch) DTS-HD
OOOOO dts-HD MSTR/HIRES
L, C, R, SL, SR, SBL, SBR, LFE
(,ex1,ex2)
Dolby D (2ch) Neo:6
OOOOO
2
DIGITAL L, R
Dolby D (2ch Surr) Neo:6
OOOOO
2
DIGITAL L, R, S
Dolby Digital Plus (2ch) Neo:6
OOOOO
2
DIGITAL PLUS L, R
Dolby TrueHD (2ch) Neo:6
OOOOO
2
TrueHD L, R
SA-CD (2ch) Neo:6
OOOOO DSD L, R
PCM (Audio) Neo:6 OOOOO PCM L, R
HDCD Neo:6 OOOOO PCM, HDCD L, R
Analog Neo:6 OOOOO ANALOG -
CS
II
(Cinema
/Music
/ Mono)
Dolby D (2ch) CSII
OOOOO
2
DIGITAL L, R
Dolby D (2ch Surr) CSII
OOOOO
2
DIGITAL L, R, S
SA-CD (2ch) CSII
OOOOO DSD L, R
PCM (Audio) CSII OOOOO PCM L, R
HDCD CSII OOOOO PCM, HDCD L, R
Analog CSII OOOOO ANALOG -
NEURAL- THX Dolby D (2ch) NEURAL_THX OOOOO
2
DIGITAL L, R
Dolby D (2ch Surr) NEURAL_THX
OOOOO
2
DIGITAL L, R, S
SA-CD (2ch) NEURAL_THX
OOOOO DSD L, R
PCM (Audio) NEURAL_THX OOOOO PCM L, R
HDCD NEURAL_THX OOOOO PCM, HDCD L, R
Analog NEURAL_THX OOOOO ANALOG -
Surround Mode Input Signal Decoding
Output Channel Front information display
L/R C
SL
SR
SBL
SBR
SubW Signal format indicators Channel status
STEREO Dolby Surr.EX Stereo
O- - - O
2
DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Stereo
O- - - O
2
DIGITAL L, C, R, SL, SR, LFE
Dolby D (2ch) Stereo
O- - - O
2
DIGITAL L, R
Dolby D (2ch Surr) Stereo
O- - - O
2
DIGITAL L, R, S
Dolby Digital Plus (2ch) Stereo
O- - - O
2
DIGITAL PLUS L, R
Dolby Digital Plus (5.1ch) Stereo
O- - - O
2
DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby Digital Plus (6.1ch) Stereo
O- - - O
2
DIGITAL PLUS L, C, R, SL, SR, S, LFE (,ex1)
Dolby Digital Plus (7.1ch) Stereo
O- - - O
2
DIGITAL PLUS L, C, R, SL, SR, SBL, SBR, LFE
Dolby TrueHD (2ch) Stereo
O- - - O
2
TrueHD L, R
Dolby TrueHD (5.1ch) Stereo
O- - - O
2
TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
Dolby TrueHD (6.1ch) Stereo
O- - - O
2
TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
Dolby TrueHD (7.1ch) Stereo
O- - - O
2
TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-ES Stereo
O- - - O dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 Stereo O- - - O dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) Stereo
O- - - O dts L, C, R, SL, SR, LFE
DTS-HD (2ch) Stereo O- - - O dts-HD MSTR/HIRES L, R
DTS-HD (5.1ch) Stereo O- - - O dts-HD MSTR/HIRES L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-HD (6.1ch) Stereo O- - - O dts-HD MSTR/HIRES L, C, R, SL, SR, S, LFE (,ex1,ex2)
DTS-HD (7.1ch) Stereo
O- - - O dts-HD MSTR/HIRES
L, C, R, SL, SR, SBL, SBR, LFE
(,ex1,ex2)
Multi Ch-PCM Stereo
O- - - O PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 96kHz Stereo O- - - O PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) Stereo
O- - - O DSD L, C, R, SL, SR, LFE
SA-CD (2ch) Stereo O- - - O DSD L, R
PCM (Audio) Stereo O- - - O PCM L, R
PCM 96kHz Stereo O- - - O PCM L, R
HDCD Stereo O- - - O PCM, HDCD L, R
Analog Stereo O- - - O ANALOG -
Dolby Virtual
Speaker
Dolby Surr.EX Dolby Virtual Speaker
O- - - -
2
DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Virtual Speaker
O- - - -
2
DIGITAL L, C, R, SL, SR, LFE
Dolby D (2ch)
PL
II
+ Dolby Virtual Speaker O- - - -
2
DIGITAL L, R
Dolby D (2ch Surr)
PL
II
+ Dolby Virtual Speaker O- - - -
2
DIGITAL L, R, S
DTS-ES Dolby Virtual Speaker
O- - - - dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 Dolby Virtual Speaker O- - - - dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) Dolby Virtual Speaker O- - - - dts L, C, R, SL, SR, LFE
Multi Ch-PCM Dolby Virtual Speaker O- - - - PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) Dolby Virtual Speaker
O- - - - DSD L, C, R, SL, SR, LFE
SA-CD (2ch) PL
II
+ Dolby Virtual Speaker O- - - - DSD L, R
PCM (Audio) PL
II
+ Dolby Virtual Speaker O- - - - PCM L, R
HDCD PL
II
+ Dolby Virtual Speaker O- - - - PCM, HDCD L, R
Analog PL
II
+ Dolby Virtual Speaker O- - - - ANALOG -
Multi Ch.
Movie
Music
(O): Movie mode only.
Dolby Surr.EX Dolby Digital EX O (O) OOO
2
DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1
O (O) O-O
2
DIGITAL L, C, R, SL, SR, LFE
Dolby D (2ch) Multi Channel
O (O) OOO
2
DIGITAL L, R
Dolby D (2ch Surr) Multi Channel
O (O) OOO
2
DIGITAL L, R, S
DTS-ES DTS-ES
O (O) OOO dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS-96/24 O (O) O-O dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1 O (O) O-O dts L, C, R, SL, SR, LFE
Multi Ch-PCM Multi Ch-PCM O (O) O-O PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 96kHz Multi Ch-PCM 96kHz O (O) O-O PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) SA-CD (5.1ch)
O (O) O-O DSD L, C, R, SL, SR, LFE
SA-CD (2ch) Multi Channel O (O) OOO DSD L, R
PCM (Audio) Multi Channel O (O) OOO PCM L, R
HDCD Multi Channel O (O) OOO PCM, HDCD L, R
Analog Multi Channel O (O) OOO ANALOG -
SR5003U1ENG33.indd69 08.7.44:49:21PM

Marantz SR5003 Specifications

General

Channels	7.1
HDMI Inputs	3
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs	2 Optical, 2 Coaxial
Analog Audio Inputs	6
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	105 dB
Total Harmonic Distortion	0.08%
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Dolby Decoding	Dolby Digital Plus, Dolby TrueHD
DTS Decoding	DTS-HD Master Audio
Input Impedance	47 kOhm
Video Conversion	Analog to HDMI
Audio Decoders	Dolby TrueHD, DTS-HD Master Audio
Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
