6-2 CHECK AUTO
These menus are for confi rming the results of AUTO
SETUP function equalizer measurement (FRONT,
AUDYSSEY FLAT, AUDYSSEY).
1.
Select “6. ACOUSTIC EQ” from MAIN MENU
with the 3
or 4 cursor buttons and press the
ENTER button.
2.
Select “CHECK AUTO” with the 3 or 4 cursor
buttons.
3.
Press the ENTER button to enter the
selection.
CHECK AUTO
MD:AUDYSSEY 63 0.0
CH:FL 125 0.0
250 0.0
500 0.0
1k 0.0
2k 0.0
4k 0.0
8k 0.0
16k 0.0
RETURN EXIT
63
125 500 2k 8k
250 1k 4k 16k
+9
0dB
-20
Select MD (mode) with the 3 / 4 cursor buttons
followed by the desired equalizer (“AUDYSSEY”,
“FRONT”, “AUDYSSEY FLAT”).
CH:
Select the channel to check with the 1 or 2 cursor
buttons.
Notes:
• The frequency will not be exactly the same as in the
Preset G. EQ modes.
• FL and FR are not indicated on the FRONT mode.
4.
Once fi nished checking, select “RETURN” with
the 3 / 4 cursor buttons and press the ENTER
button to return to the “6. ACOUSTIC EQ”
menu.
6-1 PRESET G. EQ ADJ
These modes allow you to set a 9-band graphic
equalizer for each of the 7 channels.
1.
Select “6. ACOUSTIC EQ” from MAIN MENU
with the 3 or 4 cursor buttons and press the
ENTER button.
2.
Select “PRESET G. EQ ADJ” with the 3 or 4
cursor buttons.
3.
Press the ENTER button to enter the
selection.
63
125 500 2k 8k
250 1k 4k 16k
PRESET ADJUST
RESET:CH 63 0.0
CH :FL 125 0.0
250 0.0
500 0.0
1k 0.0
2k 0.0
4k 0.0
8k 0.0
16k 0.0
RETURN EXIT
+9
0dB
-20
RESET:
Using the 1 or 2 cursor buttons, select the
channel(s) to be reset to either the currently
displayed channel (“CH”) or all channels (“ALL”),
and press the ENTER button to enter the setting.
“ALL” : Resets all channels.
“CH” : Resets only the currently displayed
channel.
CH:
Select the channel (“FL”, “C”, “FR”, “SR”, “SBR”,
“SBL” or “SL”) to adjust with the 1 or 2 cursor
buttons, and switch to the adjustment mode with
the 4 cursor button.
Frequency:
Select the target frequency on the graph with the
1 or 2 cursor buttons and press the ENTER button
to enter the selection. Adjust the level with the 3 or
4 cursor buttons. (Note that this can be adjusted
to any level between –20 and +9 dB in 0.5 dB
increments.)
Move to the next frequency with the 1 or 2 cursor
buttons, and adjust the level.
After you complete this portion of the setup, press
the ENTER button to enter the settings. Move cursor
to “RETURN” with the 3, 4 cursor buttons and press
the ENTER button.
