Marantz SR5010/U1B - Page 75

Input
CVBS / COMPONENT
A
Check the input signal to the VIDEO
DECODER.
Can a signal be conrmed at the follow-
ing points?
HDMI PCB
V : R2092
COMPONENT-Y : R2089
COMPONENT-Cb : R2091
COMPONENT-Cr : R2090
Check the connection between the
boards.
Input CVBS : Check B
Input COPONENT : Check C
Output COMPONENT NG : Check C-4
Output HDMI NG : See 3. HDMI/DVI
q
NO NO
YES
75
