Marantz SR8001 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
61
/
U1B ns
p
ns
p
PANEL REAR PANEL SR8001 U CKF7A306Z
JW14 90M-YU002390R 90M-YU002390R FPC 21P 100MM FPC CWC1B4A21A100B
JW15 90M-YU002410R 90M-YU002410R FPC 17P 100MM FPC CWC1C4A17B100B
JW16 90M-YU002400R 90M-YU002400R FPC 21P 300MM FPC CWC1B4A21A300A
JW17 90M-YU002430R 90M-YU002430R FPC 15P 100MM FPC CWC3B4A15A100A
JW18 90M-YU002450R 90M-YU002450R FPC 25P 170MM FPC CWC3B4A25A170B
JW20
/
U1B ns
p
90M-YU002460R FPC 15P 150MM FPC CWC3C4A15B150B
JW21
/
N1B ns
p
ns
p
CORD WIRE ASSY CWB4F232500UU
JW21
/
N1G ns
p
ns
p
CORD WIRE ASSY CWB4F232500UU
JW21
/
N1S ns
p
ns
p
CORD WIRE ASSY CWB4F232500UU
JW23 ns
p
ns
p
CORD WIRE ASSY CWZSR7001BN92A
JW24 90M-YU002380R 90M-YU002380R FPC 17P 80MM FPC CWC1B4A17A080A
JW25 90M-YU002420R 90M-YU002420R FPC 11P 130MM FPC CWC3B4A11A130A
JW26 90M-YU002440R 90M-YU002440R FPC 17P 170MM FPC CWC3B4A17A170B
JW27
/
U1B ns
p
90M-YU001880R FPC 15P 200MM FPC CWC1C4A15B200B
JW28
/
N1B 90M-YU001890R 90M-YU001890R FPC 17P 200MM FPC CWC1C4A17B200B
JW28
/
N1G 90M-YU001890R 90M-YU001890R FPC 17P 200MM FPC CWC1C4A17B200B
JW28
/
N1S 90M-YU001890R 90M-YU001890R FPC 17P 200MM FPC CWC1C4A17B200B
RC91 90M-YJ002690R 90M-YJ002690R TERMINAL ! R-301
(
187-2P
)
10A/250V HJJ8A001Z
90M-FC500120R 90M-FC500120R FERRITE CORE FERRITE CORE CLZ9Z070Z
90M-FC500130R 90M-FC500130R FERRITE CORE FERRITE CORE CLZ9Z071Z
90M-FC500040R 90M-FC500040R FERRITE CORE FERRITE CORE
(
21.2X6.4X12.7
)
K5C
T
CLZ9Z028Z
90M-FC500030R 90M-FC500030R FERRITE CORE FERRITE RING 29X7.7X19 CLZ9W003Z
ns
p
ns
p
CORD WIRE ASSY CWZSR7001BN92
PACKING
/
N1B 00M06CW851310 00M06CW851310 USER GUIDE USER GUIDE SR8001 N CQX1A1093Z
/
N1G 00M06CW851310 00M06CW851310 USER GUIDE USER GUIDE SR8001 N CQX1A1093Z
/
N1S 00M06CW851310 00M06CW851310 USER GUIDE USER GUIDE SR8001 N CQX1A1093Z
/
U1B ns
p
00M06CW851250 USER GUIDE USER GUIDE SR8001 U CQX1A1094Z
00MZK06CW0010 00MZK06CW0010 UNIT KIT REMOTE CONTROLLER RC8001SR CARTSR8001
62
/
N1B 90M-ZC000320R 90M-ZC000320R MAINS CORD ! MAINS CORD 2WIRE 10A/250V CJA2B054Z
62
/
N1G 90M-ZC000320R 90M-ZC000320R MAINS CORD ! MAINS CORD 2WIRE 10A/250V CJA2B054Z
62
/
N1S 90M-ZC000320R 90M-ZC000320R MAINS CORD ! MAINS CORD 2WIRE 10A/250V CJA2B054Z
62
/
U1B ns
p
90M-ZC000310R MAINS CORD ! MAINS CORD UL 032508/12 CJA2A070Z
00M05CW009010 00M05CW009010 MICROPHONE MIC AUDYSSEY CMICROSR8001
NOT STANDARD SPARE PART
ns
p
00M06CW801010 PACKING CASE PACKING CASE SR8001 CPG1A807W
/
N1B ns
p
00M06CW805010 MASS CARTON SR8001 MASTER PKG CPG1A808Y
/
N1G ns
p
00M06CW805010 MASS CARTON SR8001 MASTER PKG CPG1A808Y
/
N1S ns
p
00M06CW805010 MASS CARTON SR8001 MASTER PKG CPG1A808Y
ns
p
00M05CW809010 CUSHION PAD SNOW L CPS1A744
ns
p
00M05CW809020 CUSHION PAD SNOW R CPS1A745
31
/
N1B ns
p
00M05CW257010 LID TOP COVER
(
BLACK
)
CKC1A170K117
31
/
N1G ns
p
00M05CW257110 LID TOP COVER
(
GOLD
)
CKC1A170K118
31
/
N1S ns
p
00M05CW257210 LID TOP COVER
(
SILVER
)
CKC1A170G14
31
/
U1B ns
p
00M05CW257010 LID TOP COVER
(
BLACK
)
CKC1A170K117
ns
p
00M10BW067010 CAP COVER FOR FRONT JACK CGR1A344
ns
p
90M-ZA000240R ANTENNA AM LOOP ANT CSA1A020Z
ns
p
90M-ZA000210R ANTENNA ANT FM WIRE
(
PIGTAIL
)
CSA1A007
135
