Marantz SR8001 Service Manual

1
FM TUNER SECTION
Frequency Range ......................87.5 - 108.0 MHz [ /K /N /U ]
Usable Sensitivity .................................. IHF 1.8 µV/16.4 dBf
Signal to Noise Ratio ..........................Mono/Stereo 75/70 dB
Distortion ........................................... Mono/Stereo 0.2/0.3 %
Stereo Separation ............................................... 1 kHz 45 dB
Alternate Channel Selectivity ...................... ± 300 kHz 60 dB
Image Rejection ............................................... 98 MHz 70 dB
Tuner Output Level ..................1 kHz, ± 75 kHz Dev 800 mV
AM TUNER SECTION
Frequency Range ............................. 531 - 1602 kHz [ /K /N ]
..................................520 - 1710 kHz [ /U ]
Signal to Noise Ratio .................................................... 50 dB
Usable Sensitivity .............................................. Loop 400 µV
Distortion ........................................ 400Hz, 30 % Mod. 0.5 %
Selectivity ...................................................... ± 20 kHz 70 dB
HDMI SECTION
Version ........................................................... 1.2 [INPUT]
....................................................... 1.1 [OUTPUT]
AUDIO SECTION
Power Output (20 Hz - 20 kHz/THD=0.08%)
Front L&R ................................................ 8 ohms 125 W / Ch
Center ...................................................... 8 ohms 125 W / Ch
Surround L&R .......................................... 8 ohms 125 W / Ch
Surround Back L&R ................................. 8 ohms 125 W / Ch
Front L&R ................................................ 6 ohms 160 W / Ch
Center ...................................................... 6 ohms 160 W / Ch
Surround L&R .......................................... 6 ohms 160 W / Ch
Surround Back L&R ................................. 6 ohms 160 W / Ch
Input Sensitivity/Impedance ...................... 168 mV/ 47 kohms
Signal to Noise Ratio
(Analog Input / Pure Direct) ................................. 105 dB
Frequency Response
(Analog Input / Pure Direct) ........ 8 Hz - 100 kHz (± 3 dB)
(Digital Input / 96 kHz PCM) ......... 8 Hz - 45 kHz (± 3 dB)
VIDEO SECTION
Television Format ..................................................NTSC/PAL
Input Level/Impedance ..................................1 Vp-p/75 ohms
Output Level/Impedance ................................1 Vp-p/75 ohms
Video Frequency Response .............. 5 Hz to 8 MHz (- 1 dB)
Video Frequency (Component) ....... 5 Hz to 80 MHz (- 1 dB)
S/N ................................................................................ 60 dB
GENERAL
Power Requirement .............................. AC 220 V 50 Hz [ /K ]
.........................AC 230 V 50/60 Hz [ /N ]
..............................AC 120 V 60 Hz [ /U ]
Power Consumption ............................................ 790 W [ /N ]
..............................................6.5 A [ /U ]
Weight ....................................................... 15.0 kg (33.1 lbs)
ACCESSORIES
Remote Control Unit RC8001SR ..........................................1
AAA-size batteries ............................................................... 2
Microphone ........................................................................... 1
FM Antenna ..........................................................................1
AM Loop Antenna .................................................................1
Front AUX Jack Cover ..........................................................1
AC cable ...............................................................................1
1. TECHNICAL SPECIFICATIONS
DIMENSIONS
DIMENSIONS
D
I
G
ITA
L
R
L
V
IDE
O
S
-VIDE
O
A
UX 1 INPUT
A
U
DI
O
V
O
LUM
E
UP
D
O
WN
S
TANDBY
P
H
O
NE
S
READY
I
NPUT
S
ELE
C
T
O
R
A
V
S
URR
O
UND RE
C
EIVER
S
R8001
MultE
Q
ENTER
MENU
P
U
RE DIRE
C
TTHX
7.1
C
H INPUT
MO
DE AUT
O
MULTI
A
/
B
T
-M
O
DE
MEM
O
RY
C
LEAR
DI
S
PLA
Y
EXIT
S
PEAKER
S
BAND
MI
C
PU
RE DIRE
C
T
SU
RR
OU
N
D
S
PEAKE
R
MULTI
D
S
D
P
O
WER
O
N
/S
TANDBY
L
C
R
SL S SR
S
L
F
E
DI
G
ITAL
SU
RR
OU
N
D
V-
O
FF
D
I
SP
MULTI
A
U
T
O
TUNED
ST
S
PKR A B
N
I
G
HT
PEAK
ANAL
OG
DI
G
ITAL
ATT
S
LEEP
SURR DIRECT
AU
T
O
DI
SC
6
.
1
MTX
6
.
1
E
Q
PCM
A
AC
7
-1/4 ins
.
(
184 mm
)
9
/16 ins.
(
14 mm)
6-3/4 ins.
(170 mm
)
17-5/16
i
ns.
(
440 mm
)
1
3
/1
6
i
n
s.
(
20 mm
)
7/
8i
n
s
(
22 mm
)
1
3-15/16 ins
(
354 mm
)
1
5
-
5
/
8
i
n
s
(396 mm)
