139
100 ~RES I YES I _RES L H RESET
101 P20/TIOCA3 I/O,O O I CPU_NMI HDMI CPU WRITE MODE (H8/36087)
102 P21/TIOCB3 I/O,I/O T_IN I IR_RECEIVER_IN --RFC
103 P22/TIOCC3 I/O,I/O I I SPIO_ENA L H Communication Enable from TI DSP (DA708)
104 P23/TIOCD3 I/O,I/O O I _TI_RST L H Reset for TI DSP (DA708)
105 P24/TIOCA4 I/O,I/O O I _SPIO_SCS L H Chip Select for TI DSP (DA708)
106 P25/TIOCB4 I/O,I/O I I XSTATE L H DIR CKST (LC89057W)
107 P26/TIOCA5 I/O,I/O T_OUT I M_RC_OUT - L RC BUS MULT OUT
108 P27/TIOCB5 I/O,I/O T_IN O M_RC_IN L H Multi RC5 In Detect Signal
109
P17/TIOCB2/
TCLKD
I/O,I/O,I/O O I N.C - L OPEN
110
P16/TIOCA2/
~IRQ1
I/O,I/O,I INT INT WAKEUP
↑
- Standby Mode Release
111
P15/TIOCB1/
TCLKC
I/O,I/O,I/O T_IN I VSYNC
↑
- V-sync Det. & Change OSD (LC74781)
112
P14/TIOCA1/
~IRQ0
I/O,I/O,I INT I RERR H - DIR Error (LC89057W)
113
P13/
TIOCD0/
TCLKB
I/O,I/O,I/O T_OUT O RC_OUT - L RC BUS OUT
114
P12/
TIOCC0/
TCLKA
I/O,I/O,I/O O I/O V_SDA - H
I2C Data for VIDEO DEC/ENC (ADV7401/
ADV7320/CD0040AF)
115 P11/TIOCB0 I/O,I/O O O V_SCL - H
I2C Clock for VIDEO DEC/ENC (ADV7401/
ADV7320/CD0040AF)
116 P10/TIOCA0 I/O,I/O T_IN I RC_IN
↑↓
- IR In for RC-5
117 Vss I YES I VSS - - GND
118 P2Vcc I YES I VCC - - +3.3V’
119 P37/TxD4 I/O,O SO O XM_RXD - H UART for XM Module
120 P36/RxD4 I/O,I SI I XM_TXD - H UART for XM Module
121
P35/SCK1/
SCK4/SCL0/
~IRQ5
I/O,I/O,I/O,I/O,I SC I CPU SCL - H HDMI CPU I/F (H8/36087)
122
P34/RxD1/
SDA0
I/O,I,I/O SIO I CPU SDA - H HDMI CPU I/F (H8/36087)
123
P33/TxD1/
SCL1
I/O,O,I/O O I CPU_RST L H HDMI CPU Reset (H8/36087)
124
P32/SCK0/
SDA1/~IRQ4
I/O,I/O,I/O,I INT I HDMI_MUTE - L HDMI MUTE (Sil9033)
125 P31/RxD0 I/O,I SI I RXD - H UART for RS232C
126 P30/TxD0 I/O,O SC I TXD - H UART for RS232C
127 P77/TxD3 I/O,O SO I SPIO_SIMO - H Serilal Data Out for TI DSP (DA708)
128 P76/RxD3 I/O,I SI I SPIO_SOMI - L Serial Data In from TI DSP (DA708)
129
P75/TMO3/
SCK3
I/O,I/O,I/O SC I SPIO_CLK - L Serial Clock Out for TI DSP (DA708)
130
P74/TMO2/
~MRES
I/O,O O O IICCLK - L I2C Clock for E2PROM (AT24C128)
131 P73/TMO1 I/O,O I/O I/O IICDATA - L I2C Data for E2PROM (AT24C128)
132 P72/TMO0 I/O,O O I XM_CMD H L DTIC mode select (XM Module)
133
P71/TMRI23/
TMCI23
I/O,O,O O I XM_RST L L Reset for XM DTIC (XM Module)
134
P70/TMRI01/
TMCI01
I/O,O,O O I _XM_DAC_RST L L DAC Reset for XM_Module (CS4392)
135 PG4 I/O O I XM_MUTE H H Mute On for XM Module
136 PG3 I/O O I N.C - L OPEN
137 PG2 I/O O O N.C - L OPEN
138 PG1/~IRQ7 I/O,I INT I _AMUTE0 L H MUTE Contorol from TI DSP (DA708)
139 PG0/~IRQ6 I/O,I INT I XM_IRQ L H XM error detect (XM Module)
140 PE0 I/O O XM_ON H L Control Power to XM/DT Bus (XM Module)
141 PE1 I/O O I _CEEX L H
Serial to Parallel Expander for Video Strobe
(74HC4094 x3pcs)
142 PE2 I/O O I Y_OSD H L Y/C_OSD_IC_BYPASS (NJM2595)
143 PE3 I/O O I CVBS_OSD H L CVBS_OSD_IC_BYPASS (NJM2595)
144 PE4 I/O O I _CEOSD L H Video Circuit (LC74781)
IC11 : HD64F2505
pin
No
Port Name
Mode7
I/O use STBY Name
Port Setting
Note
Act. init
