Marantz SR8001 - Page 149

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
AMP Q705 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
AMP Q707 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
AMP Q709 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
AMP Q711 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
AMP Q713 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
AMP Q715 90M-HT600030R 90M-HT600030R TRS. KTA1024Y HVTKTA1024YT
AMP Q717 00MHT800941B0 00MHT800941B0 TRS. KTC3206Y HVTKTC3206YAT
AMP Q719 00MHC20002080 00MHC20002080 IC ! SAP17NLFNO.552 HVISAP17N
AMP Q721 00MHC20001080 00MHC20001080 IC ! SAP17PLFNO.552 HVISAP17P
AMP Q723 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
AMP Q801 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
AMP Q802 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
AMP Q803 00MBA20001000 00MBA20001000 TRS. KRC102M HVTKRC102MT
AMP Q804 90M-BA001450R 90M-BA001450R TRS. KRA107M HVTKRA107MT
AMP Q805 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
AMP Q806 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
AMP Q807 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
AMP Q808 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
AMP R401 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
AMP R402 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
AMP R403 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
AMP R404 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
AMP R405 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
AMP R406 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
AMP R407 ns
p
ns
p
RES. 12K OHM 1/5W J CRD20TJ123T
AMP R408 ns
p
ns
p
RES. 12K OHM 1/5W J CRD20TJ123T
AMP R409 ns
p
ns
p
RES. 12K OHM 1/5W J CRD20TJ123T
AMP R410 ns
p
ns
p
RES. 12K OHM 1/5W J CRD20TJ123T
AMP R411 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
AMP R412 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
AMP R413 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
AMP R414 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
AMP R415 ns
p
ns
p
RES. 68 OHM 1/5W J CRD20TJ680T
AMP R416 ns
p
ns
p
RES. 68 OHM 1/5W J CRD20TJ680T
AMP R417 ns
p
ns
p
RES. 68 OHM 1/5W J CRD20TJ680T
AMP R418 ns
p
ns
p
RES. 68 OHM 1/5W J CRD20TJ680T
AMP R419 90M-NB000010R 90M-NB000010R RES. LT20001/6S J HRT16C1512000JT
AMP R420 90M-NB000010R 90M-NB000010R RES. LT20001/6S J HRT16C1512000JT
AMP R421 90M-NB000010R 90M-NB000010R RES. LT20001/6S J HRT16C1512000JT
AMP R422 90M-NB000010R 90M-NB000010R RES. LT20001/6S J HRT16C1512000JT
AMP R423 ns
p
ns
p
RES. 330K OHM 1/6W J CRD20TJ334T
AMP R424 ns
p
ns
p
RES. 330K OHM 1/6W J CRD20TJ334T
AMP R425 ns
p
ns
p
RES. 330K OHM 1/6W J CRD20TJ334T
AMP R426 ns
p
ns
p
RES. 330K OHM 1/6W J CRD20TJ334T
AMP R427 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
AMP R428 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
AMP R429 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
AMP R430 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
AMP R431 ns
p
ns
p
RES. 10 OHM 1/4W J CRD25TJ100T
AMP R432 ns
p
ns
p
RES. 10 OHM 1/4W J CRD25TJ100T
AMP R433 ns
p
ns
p
RES. 10 OHM 1/4W J CRD25TJ100T
AMP R434 ns
p
ns
p
RES. 10 OHM 1/4W J CRD25TJ100T
AMP R435 ns
p
ns
p
RES. 27 OHM 1/6W J CRD20TJ270T
AMP R436 ns
p
ns
p
RES. 27 OHM 1/6W J CRD20TJ270T
AMP R439 ns
p
ns
p
RES. 120 OHM 1W J KRG1SANJ121RT
AMP R440 ns
p
ns
p
RES. 120 OHM 1W J KRG1SANJ121RT
AMP R441 ns
p
ns
p
RES. 120 OHM 1W J KRG1SANJ121RT
AMP R442 ns
p
ns
p
RES. 120 OHM 1W J KRG1SANJ121RT
AMP R443 ns
p
ns
p
RES. 120 OHM 1W J KRG1SANJ121RT
AMP R444 ns
p
ns
p
RES. 120 OHM 1W J KRG1SANJ121RT
AMP R445 ns
p
ns
p
RES. 47 OHM 1W J KRG1SANJ470RT
AMP R446 ns
p
ns
p
RES. 47 OHM 1W J KRG1SANJ470RT
AMP R449 ns
p
ns
p
RES. 15 OHM 1/6W J CRD20TJ150T
AMP R450 ns
p
ns
p
RES. 15 OHM 1/6W J CRD20TJ150T
AMP R451 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100T
AMP R452 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100T
AMP R453 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
