NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
AMP R806 ns
p
ns
p
RES. 68K OHM 1/5W J CRD20TJ683T
AMP R807 ns
p
ns
p
RES. 68K OHM 1/5W J CRD20TJ683T
AMP R810 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153T
AMP R811 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
AMP R812 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
AMP R813 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
AMP R814 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
AMP R815 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153T
AMP R816 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562T
AMP R818 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
AMP R819 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
AMP R820 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
AMP R821 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
AMP R822 ns
p
ns
p
RES. 24K OHM 1/5W J CRD20TJ243T
AMP R823 ns
p
ns
p
RES. 6.8K OHM 1/5W J CRD20TJ682T
AMP R824 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
AMP R825 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
AMP R826 ns
p
ns
p
RES. 51K OHM 1/5W J CRD20TJ513T
AMP R827 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153T
AMP R828 ns
p
ns
p
RES. 7.5K OHM 1/5W J CRD20TJ752T
AMP VR41 90M-RA001090R 90M-RA001090R TRIM. RES. 220 OHM CVN1RE221B01T
AMP VR42 90M-RA001090R 90M-RA001090R TRIM. RES. 220 OHM CVN1RE221B01T
AMP VR51 90M-RA001090R 90M-RA001090R TRIM. RES. 220 OHM CVN1RE221B01T
AMP VR52 90M-RA001090R 90M-RA001090R TRIM. RES. 220 OHM CVN1RE221B01T
AMP VR61 90M-RA001090R 90M-RA001090R TRIM. RES. 220 OHM CVN1RE221B01T
AMP VR62 90M-RA001090R 90M-RA001090R TRIM. RES. 220 OHM CVN1RE221B01T
AMP VR71 90M-RA001090R 90M-RA001090R TRIM. RES. 220 OHM CVN1RE221B01T
COMPONENT PWB
(
CUP11894Z
)
COMP BK91 ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
COMP BK92 ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
COMP C801 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C802 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
COMP C803 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C804 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
COMP C805 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C806 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
COMP C807 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C808 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C809 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C811 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C812 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
COMP C813 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
COMP C814 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C815 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C819 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C840 ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
COMP C841 ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
COMP C842 ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
COMP C843 ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
COMP C844 ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
COMP C845 ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
COMP C846 ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
COMP C847 ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
COMP C851 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
COMP C852 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
COMP C853 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
COMP C854 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
COMP C856 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
COMP C857 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
COMP C858 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
COMP C859 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
COMP C860 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
COMP C861 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
COMP C862 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
COMP C863 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
COMP C901 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
COMP C902 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
