Marantz SR8001 - IC35: SiI 9030 CTU-7 Pin Description

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
COMP C973 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C974 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C975 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C976 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C977 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
COMP C978 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
COMP C979 ns
p
00MOA47701020 ELECT CAP. 470UF 10V CCEA1AH471T
COMP C980 ns
p
00MOA47701020 ELECT CAP. 470UF 10V CCEA1AH471T
COMP C981 ns
p
00MOA47701020 ELECT CAP. 470UF 10V CCEA1AH471T
COMP C982 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C983 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C984 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C986 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
COMP C987 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
COMP C988 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C989 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
COMP C990 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C991 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
COMP C992 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C993 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
COMP C994 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C995 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
COMP C996 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
COMP C997 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP C998 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
COMP C999 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
COMP CN41 ns
p
ns
p
CONN. 17P WAFER CARD CABLE CJP17GA117ZY
COMP CN42 ns
p
ns
p
CONN. CARDCABLE CJP11GA117ZY
COMP CN43 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01ZY
COMP IC91 90M-HC109830R 90M-HC109830R IC NJM2584M HVINJM2584MTE1
COMP IC92 90M-HC109830R 90M-HC109830R IC NJM2584M HVINJM2584MTE1
COMP IC93 90M-HC109830R 90M-HC109830R IC NJM2584M HVINJM2584MTE1
COMP IC94 00MHC10236090 00MHC10236090 IC NJM2586AM HVINJM2586AMTE1
COMP IC95 00MHC10239090 00MHC10239090 IC NJM2581M HVINJM2581MTE1
COMP IC96 90M-HC109830R 90M-HC109830R IC NJM2584M HVINJM2584MTE1
COMP IC97 90M-HC109830R 90M-HC109830R IC NJM2584M HVINJM2584MTE1
COMP IC98 90M-HC109830R 90M-HC109830R IC NJM2584M HVINJM2584MTE1
COMP IC99 00MHC10236090 00MHC10236090 IC NJM2586AM HVINJM2586AMTE1
COMP JK91 90M-YT004360R 90M-YT004360R TERMINAL JACK BOARD GOLD PLATE CJJ4R046Z
COMP JK92 90M-YT004360R 90M-YT004360R TERMINAL JACK BOARD GOLD PLATE CJJ4R046Z
COMP JK93 90M-YT004360R 90M-YT004360R TERMINAL JACK BOARD GOLD PLATE CJJ4R046Z
COMP Q851 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
COMP Q852 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
COMP Q853 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
COMP Q854 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
COMP Q855 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
COMP Q856 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
COMP Q857 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
COMP Q858 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
COMP Q859 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
COMP Q860 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
COMP Q861 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
COMP Q862 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
COMP R851 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
COMP R852 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
COMP R853 ns
p
00MNN05102610 CHIP RES. 1K OHM 1/10W J CRJ10DJ102T
COMP R854 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
COMP R855 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
COMP R856 ns
p
00MNN05102610 CHIP RES. 1K OHM 1/10W J CRJ10DJ102T
COMP R857 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
COMP R858 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
COMP R859 ns
p
00MNN05102610 CHIP RES. 1K OHM 1/10W J CRJ10DJ102T
COMP R860 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
COMP R861 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
COMP R862 ns
p
00MNN05102610 CHIP RES. 1K OHM 1/10W J CRJ10DJ102T
COMP R863 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
COMP R864 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
189
