NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
DSP RC83 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
DSP RC84 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
DSP RC87 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
DSP RC88 ns
p
00MNN05562610 CHIP RES. 5.6K OHM 1/10W J CRJ10DJ562T
DSP RC89 ns
p
00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T
DSP RN10 90M-BW000390R 90M-BW000390R RES. COMPO. ARC 241 100R CRJ104DJ101T
DSP RN11 90M-BW000390R 90M-BW000390R RES. COMPO. ARC 241 100R CRJ104DJ101T
DSP RN12 90M-BW000390R 90M-BW000390R RES. COMPO. ARC 241 100R CRJ104DJ101T
DSP RN13 90M-BW000390R 90M-BW000390R RES. COMPO. ARC 241 100R CRJ104DJ101T
DSP RN14 90M-BW000390R 90M-BW000390R RES. COMPO. ARC 241 100R CRJ104DJ101T
DSP RN15 90M-BW000390R 90M-BW000390R RES. COMPO. ARC 241 100R CRJ104DJ101T
DSP RN16 90M-BW000390R 90M-BW000390R RES. COMPO. ARC 241 100R CRJ104DJ101T
DSP RN17 90M-BW000390R 90M-BW000390R RES. COMPO. ARC 241 100R CRJ104DJ101T
DSP RN18 90M-BW000390R 90M-BW000390R RES. COMPO. ARC 241 100R CRJ104DJ101T
DSP RN19 90M-BW000390R 90M-BW000390R RES. COMPO. ARC 241 100R CRJ104DJ101T
DSP RN20 90M-BW000390R 90M-BW000390R RES. COMPO. ARC 241 100R CRJ104DJ101T
DSP RN21 90M-BW000390R 90M-BW000390R RES. COMPO. ARC 241 100R CRJ104DJ101T
DSP RN22 90M-BW000390R 90M-BW000390R RES. COMPO. ARC 241 100R CRJ104DJ101T
DSP RO12 ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J CRJ10DJ0R0T
DSP RO13
/
U1B ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J CRJ10DJ0R0T
DSP RO14
/
N1B ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J CRJ10DJ0R0T
DSP RO14
/
N1G ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J CRJ10DJ0R0T
DSP RO14
/
N1S ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J CRJ10DJ0R0T
DSP RR10 00MNM11800020 00MNM11800020 CHIP RES. 180 OHM 1% CRJ10DF1800T
DSP RR11 00MNM11800020 00MNM11800020 CHIP RES. 180 OHM 1% CRJ10DF1800T
DSP RR13 00MNM12200020 00MNM12200020 CHIP RES. 220 OHM 1% CRJ10DF2200T
DSP RR14 00MNM1033G020 00MNM1033G020 CHIP RES. 3.3 OHM 1% CRJ10DF3R30T
DSP RR15 00MNM12200020 00MNM12200020 CHIP RES. 220 OHM 1% CRJ10DF2200T
DSP RR19 00MNM12200020 00MNM12200020 CHIP RES. 220 OHM 1% CRJ10DF2200T
DSP RR20 00MNM12200020 00MNM12200020 CHIP RES. 220 OHM 1% CRJ10DF2200T
DSP RR21 00MNM11800020 00MNM11800020 CHIP RES. 180 OHM 1% CRJ10DF1800T
DSP RR22 00MNM11800020 00MNM11800020 CHIP RES. 180 OHM 1% CRJ10DF1800T
DSP RR23 00MNM12200020 00MNM12200020 CHIP RES. 220 OHM 1% CRJ10DF2200T
DSP RR24 ns
p
00MNN05222610 CHIP RES. 2.2K OHM 1/10W J CRJ10DJ222T
DSP RR25 ns
p
00MNN05183610 CHIP RES. 18K OHM 1/10W J CRJ10DJ183T
DSP RR26 ns
p
00MNN05222610 CHIP RES. 2.2K OHM 1/10W J CRJ10DJ222T
DSP RR27 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
DSP RR28 ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
DSP RR29 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
DSP RR30 ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J CRJ10DJ0R0T
DSP RR32 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
DSP RR34 ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J CRJ10DJ0R0T
DSP RR35 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
DSP RR36 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
DSP RR37 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
DSP RR38 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
DSP RR39 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
DSP RX10 90M-HP000100R 90M-HP000100R VARISTOR POSISTOR CRTRXEF005
DSP RY10 90M-LY000380R 90M-LY000380R RELAY D3023 HSL4C008ZE
DSP SW10 90M-SP001290R 90M-SP001290R SW SPUJ19XSM011 HSH2B018Z
DSP XC10 90M-JX001190R 90M-JX001190R X'TAL 20MHZ HOX20000E220TF
DSP XC11 90M-JX001340R 90M-JX001340R X'TAL 24.576MHZ COX24576E180TF
DSP XC12 90M-JX001350R 90M-JX001350R X'TAL 24.576MHZ 10PPM COX24576E120TF
FRONT PWB
(
CUP11869Z
)
FRONT BN14 ns
p
ns
p
CORD WIRE ASSY CWB1B907450BN
FRONT BN51 ns
p
ns
p
CORD WIRE ASSY CWB1B909050EN
FRONT BN52 ns
p
ns
p
CORD WIRE ASSY CWB1B908050EN
FRONT BN53 ns
p
ns
p
CORD WIRE ASSY CWZSR7001BN53
FRONT C801 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
FRONT C802 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
FRONT C804 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C805 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
FRONT C806 ns
p
00MOA10703520 ELECT CAP. 100UF 35V CCEA1VH101T
FRONT C807 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
FRONT C809 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
FRONT C810 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
FRONT C811 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
