Marantz SR8001 - Page 171

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
FRONT SW86 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT SW87 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT SW88 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT SW89 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT SW90 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT SW91 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT SW92 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT SW95 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT SW96 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
GUIDE PWB
GUIDE CN53 ns
p
ns
p
CONN. 3PIN ANGLE CJP03GB46ZY
GUIDE CN55 ns
p
ns
p
CONN. 4P ANGLE CJP04GB46ZY
GUIDE CN85 ns
p
ns
p
CONN. 3PIN ANGLE CJP03GB46ZY
H/P PWB
(
CUP11869Z-4
)
H/P BN17 ns
p
ns
p
CORD WIRE ASSY CWB1B905540BN
H/P C874 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
H/P C875 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
H/P C876 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
H/P JK81
/
N1B 90M-YT003160R 90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z
H/P JK81
/
N1G 90M-YT003160R 90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z
H/P JK81
/
N1S 90M-YT004500R 90M-YT004500R TERMINAL JACK HEADPHONE
(
SILVER
)
CJJ2E026Z
H/P JK81
/
U1B ns
p
90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z
H/P JW12 ns
p
ns
p
CORD WIRE ASSY CWE8102050RV
H/P JW22 ns
p
ns
p
CORD WIRE ASSY CWE8102050RV
H/P R846 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
H/P R847 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
HDMI PWB
(
CUP11875Z
)
HDMI BK11 ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
HDMI BK12 ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
HDMI BN31 ns
p
ns
p
CORD WIRE ASSY CWB1D906060BM
HDMI C101 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C102 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C103 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C104 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C105 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C106 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C107 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C108 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C109 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C110 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C111 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C112 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C113 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C114 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C115 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C116 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C117 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C118 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C119 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C120 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C121 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C122 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C123 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C124 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC HCUS1H103KC
HDMI C125 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC HCUS1H103KC
HDMI C126 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C127 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C128 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C129 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C130 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C131 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C132 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C133 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C134 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C135 ns
p
00MDK96104300 CER. CAP. 0.1UF 25V ZF HCUS1E104ZF
HDMI C303 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
HDMI C304 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
