Marantz SR8001 - Page 177

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
HDMI JK11 90M-YT005010R 90M-YT005010R TERMINAL HDMI YKF45-7009 HJJ9H003Z
HDMI JK12 90M-YT005010R 90M-YT005010R TERMINAL HDMI YKF45-7009 HJJ9H003Z
HDMI JK13 90M-YT005010R 90M-YT005010R TERMINAL HDMI YKF45-7009 HJJ9H003Z
HDMI JK14 90M-YT005010R 90M-YT005010R TERMINAL HDMI YKF45-7009 HJJ9H003Z
HDMI JK31 90M-YT005010R 90M-YT005010R TERMINAL HDMI YKF45-7009 HJJ9H003Z
HDMI JK32 90M-YT005010R 90M-YT005010R TERMINAL HDMI YKF45-7009 HJJ9H003Z
HDMI L101 90M-LU000260R 90M-LU000260R CHIP INDUCT 10UH CLQ10E100MRZ
HDMI L102 90M-LU000260R 90M-LU000260R CHIP INDUCT 10UH CLQ10E100MRZ
HDMI L301 90M-LU000260R 90M-LU000260R CHIP INDUCT 10UH CLQ10E100MRZ
HDMI L302 90M-LU000260R 90M-LU000260R CHIP INDUCT 10UH CLQ10E100MRZ
HDMI L303 90M-LU000260R 90M-LU000260R CHIP INDUCT 10UH CLQ10E100MRZ
HDMI L304 90M-LU000260R 90M-LU000260R CHIP INDUCT 10UH CLQ10E100MRZ
HDMI L305 90M-LU000260R 90M-LU000260R CHIP INDUCT 10UH CLQ10E100MRZ
HDMI L306 90M-LU000260R 90M-LU000260R CHIP INDUCT 10UH CLQ10E100MRZ
HDMI L601 90M-FC900400R 90M-FC900400R FERRITE CORE BEAD CHIP 60
(
1608 SIZE
)
HLZ9R005Z
HDMI L602 90M-FC900400R 90M-FC900400R FERRITE CORE BEAD CHIP 60
(
1608 SIZE
)
HLZ9R005Z
HDMI L603 90M-FC900400R 90M-FC900400R FERRITE CORE BEAD CHIP 60
(
1608 SIZE
)
HLZ9R005Z
HDMI L604 90M-FC900400R 90M-FC900400R FERRITE CORE BEAD CHIP 60
(
1608 SIZE
)
HLZ9R005Z
HDMI L605 90M-LU000260R 90M-LU000260R CHIP INDUCT 10UH CLQ10E100MRZ
HDMI L606 90M-FC900400R 90M-FC900400R FERRITE CORE BEAD CHIP 60
(
1608 SIZE
)
HLZ9R005Z
HDMI L801 ns
p
ns
p
COIL 22UH,K HLQ02C220KT
HDMI L802 ns
p
ns
p
COIL 22UH,K HLQ02C220KT
HDMI L803 ns
p
ns
p
COIL 22UH,K HLQ02C220KT
HDMI L804 ns
p
ns
p
COIL 22UH,K HLQ02C220KT
HDMI L805 ns
p
ns
p
COIL 22UH,K HLQ02C220KT
HDMI L806 ns
p
ns
p
COIL 22UH,K HLQ02C220KT
HDMI L901 90M-LU000260R 90M-LU000260R CHIP INDUCT 10UH CLQ10E100MRZ
HDMI L902 90M-LU000260R 90M-LU000260R CHIP INDUCT 10UH CLQ10E100MRZ
HDMI L903 90M-LU000260R 90M-LU000260R CHIP INDUCT 10UH CLQ10E100MRZ
HDMI L904 90M-LU000260R 90M-LU000260R CHIP INDUCT 10UH CLQ10E100MRZ
HDMI Q101 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
HDMI Q102 90M-BA001620R 90M-BA001620R CHIP TRS. KRC103S CVTKRC103S
HDMI Q103 90M-HY200050R 90M-HY200050R F.E.T. UPA672T CVTUPA672T
HDMI Q104 90M-BA001620R 90M-BA001620R CHIP TRS. KRC103S CVTKRC103S
HDMI Q105 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
HDMI Q106 90M-BA001620R 90M-BA001620R CHIP TRS. KRC103S CVTKRC103S
HDMI Q107 90M-HY200050R 90M-HY200050R F.E.T. UPA672T CVTUPA672T
HDMI Q108 90M-BA001620R 90M-BA001620R CHIP TRS. KRC103S CVTKRC103S
HDMI Q109 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
HDMI Q110 90M-BA001620R 90M-BA001620R CHIP TRS. KRC103S CVTKRC103S
HDMI Q111 90M-HY200050R 90M-HY200050R F.E.T. UPA672T CVTUPA672T
HDMI Q112 90M-BA001620R 90M-BA001620R CHIP TRS. KRC103S CVTKRC103S
HDMI Q113 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
HDMI Q114 90M-BA001620R 90M-BA001620R CHIP TRS. KRC103S CVTKRC103S
HDMI Q115 90M-HY200050R 90M-HY200050R F.E.T. UPA672T CVTUPA672T
HDMI Q116 90M-BA001620R 90M-BA001620R CHIP TRS. KRC103S CVTKRC103S
HDMI Q117 90M-BA001620R 90M-BA001620R CHIP TRS. KRC103S CVTKRC103S
HDMI Q118 90M-BA001620R 90M-BA001620R CHIP TRS. KRC103S CVTKRC103S
HDMI Q301 90M-HY200050R 90M-HY200050R F.E.T. UPA672T CVTUPA672T
HDMI Q302 90M-BA001620R 90M-BA001620R CHIP TRS. KRC103S CVTKRC103S
HDMI Q303 90M-HY200050R 90M-HY200050R F.E.T. UPA672T CVTUPA672T
HDMI Q601 90M-HT600050R 90M-HT600050R TRS. KTA2014GR HVTKTA2014GR
HDMI Q602 90M-HT600050R 90M-HT600050R TRS. KTA2014GR HVTKTA2014GR
HDMI Q603 90M-HT600050R 90M-HT600050R TRS. KTA2014GR HVTKTA2014GR
HDMI Q604 90M-HX800010R 90M-HX800010R CHIP TRS. KRC102S HVTKRC102S
HDMI Q605 90M-HX800010R 90M-HX800010R CHIP TRS. KRC102S HVTKRC102S
HDMI Q606 90M-HX800010R 90M-HX800010R CHIP TRS. KRC102S HVTKRC102S
HDMI Q801 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
HDMI Q802 90M-HT600050R 90M-HT600050R TRS. KTA2014GR HVTKTA2014GR
HDMI Q803 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
HDMI Q804 90M-HT600050R 90M-HT600050R TRS. KTA2014GR HVTKTA2014GR
HDMI Q805 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
HDMI Q806 90M-HT600050R 90M-HT600050R TRS. KTA2014GR HVTKTA2014GR
HDMI Q807 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
HDMI Q808 90M-HT600050R 90M-HT600050R TRS. KTA2014GR HVTKTA2014GR
HDMI Q809 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
HDMI Q810 90M-HT600050R 90M-HT600050R TRS. KTA2014GR HVTKTA2014GR
211
