Marantz SR8001 - Page 183

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
HDMI RN39 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN40 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN41 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN42 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN43 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN44 90M-BW000470R 90M-BW000470R RES. COMPO. RES ARRAY 0 OHM 1608X4 CRJ104DJ0R0T
HDMI RN45 90M-BW000470R 90M-BW000470R RES. COMPO. RES ARRAY 0 OHM 1608X4 CRJ104DJ0R0T
HDMI RN61 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN62 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN63 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN64 90M-BW000470R 90M-BW000470R RES. COMPO. RES ARRAY 0 OHM 1608X4 CRJ104DJ0R0T
HDMI RN65 90M-BW000470R 90M-BW000470R RES. COMPO. RES ARRAY 0 OHM 1608X4 CRJ104DJ0R0T
HDMI RN66 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN67 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN68 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN69 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN70 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN71 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN72 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN73 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN74 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN75 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN76 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN77 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN78 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN79 90M-BW000480R 90M-BW000480R RES. COMPO. RES ARRAY 47K 1608X4 CRJ104DJ473T
HDMI RN81 90M-BW000480R 90M-BW000480R RES. COMPO. RES ARRAY 47K 1608X4 CRJ104DJ473T
HDMI RN83 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN84 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN85 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN86 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN87 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN88 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN89 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN90 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI X301 90M-JX001330R 90M-JX001330R X'TAL 27MHZ COX27000E180TF
HDMI X601 90M-JX001360R 90M-JX001360R X'TAL 28.636MHZ COX28636E330TF
HDMI X901 90M-JX001370R 90M-JX001370R X'TAL 16.000MHZ COX16000E120TF
INPUT PWB
(
CUP11871Z
)
INPUT BC72 ns
p
ns
p
CORD WIRE ASSY CWB1C902150EN
INPUT BN11 ns
p
ns
p
CORD WIRE ASSY CWB1B907300EN
INPUT BN19 ns
p
ns
p
CORD WIRE ASSY CWB1B903100EN
INPUT BN23 ns
p
ns
p
CORD WIRE ASSY CWZSR7001BN23
INPUT BN24 ns
p
ns
p
CORD WIRE ASSY CWZSR7001BN24
INPUT BN30 ns
p
ns
p
CORD WIRE ASSY CWB1D912130EN
INPUT BN46 ns
p
ns
p
CORD WIRE ASSY CWB1B904100EN
INPUT BN71 ns
p
ns
p
CORD WIRE ASSY CWZSR7001BN71
INPUT BN93 ns
p
ns
p
CORD WIRE ASSY CWB1D908450BM
INPUT C201 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C202 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C203 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C204 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C205 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C206 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C207 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C208 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C209 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C210 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C211 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C212 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C213 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C214 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C215 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C216 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C217 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C218 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
INPUT C219 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA CCUS1H471JA
217
