Marantz SR8001 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
XM R523
/
U1B ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
XM R524
/
U1B ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
XM R525
/
U1B ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
XM R526
/
U1B ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
XM R527
/
U1B ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
XM R528
/
U1B ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
XM R529
/
U1B ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
XM R530
/
U1B ns
p
00MNN05223610 CHIP RES. 22K OHM 1/10W J CRJ10DJ223T
XM R601
/
U1B ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
XM R602
/
U1B ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
XM R603
/
U1B ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J CRJ10DJ0R0T
XM R605
/
U1B ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
XM R611
/
U1B ns
p
00MNN05822610 CHIP RES. 8.2K OHM 1/10W J CRJ10DJ822T
XM R612
/
U1B ns
p
00MNN05822610 CHIP RES. 8.2K OHM 1/10W J CRJ10DJ822T
XM R613
/
U1B ns
p
00MNN05822610 CHIP RES. 8.2K OHM 1/10W J CRJ10DJ822T
XM R614
/
U1B ns
p
00MNN05822610 CHIP RES. 8.2K OHM 1/10W J CRJ10DJ822T
XM R615
/
U1B ns
p
00MNN05332610 CHIP RES. 3.3K OHM 1/10W J CRJ10DJ332T
XM R616
/
U1B ns
p
00MNN05332610 CHIP RES. 3.3K OHM 1/10W J CRJ10DJ332T
XM R617
/
U1B ns
p
00MNN05332610 CHIP RES. 3.3K OHM 1/10W J CRJ10DJ332T
XM R618
/
U1B ns
p
00MNN05332610 CHIP RES. 3.3K OHM 1/10W J CRJ10DJ332T
XM R619
/
U1B ns
p
00MNN05822610 CHIP RES. 8.2K OHM 1/10W J CRJ10DJ822T
XM R620
/
U1B ns
p
00MNN05822610 CHIP RES. 8.2K OHM 1/10W J CRJ10DJ822T
XM R621
/
U1B ns
p
00MNN05822610 CHIP RES. 8.2K OHM 1/10W J CRJ10DJ822T
XM R622
/
U1B ns
p
00MNN05822610 CHIP RES. 8.2K OHM 1/10W J CRJ10DJ822T
XM R623
/
U1B ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
XM R624
/
U1B ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J CRJ10DJ101T
XM R625
/
U1B ns
p
00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T
XM R626
/
U1B ns
p
00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T
XM R627
/
U1B ns
p
00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T
XM R628
/
U1B ns
p
00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T
XM R629
/
U1B ns
p
00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T
XM R630
/
U1B ns
p
00MNN05221610 CHIP RES. 220 OHM 1/10W J CRJ10DJ221T
XM R631
/
U1B ns
p
00MNN05222610 CHIP RES. 2.2K OHM 1/10W J CRJ10DJ222T
XM R632
/
U1B ns
p
00MNN05222610 CHIP RES. 2.2K OHM 1/10W J CRJ10DJ222T
XM R633
/
U1B ns
p
00MNN05222610 CHIP RES. 2.2K OHM 1/10W J CRJ10DJ222T
XM R634
/
U1B ns
p
00MNN05222610 CHIP RES. 2.2K OHM 1/10W J CRJ10DJ222T
XM R635
/
U1B ns
p
00MNN05474610 CHIP RES. 470K OHM 1/10W J CRJ10DJ474T
XM R636
/
U1B ns
p
00MNN05474610 CHIP RES. 470K OHM 1/10W J CRJ10DJ474T
XM R801
/
U1B ns
p
00MNM13901020 CHIP RES. 3.9KOHM/1608/1% CRJ10DF3901T
XM R802
/
U1B ns
p
00MNM11201020 CHIP RES. 1.2KOHM/1608/1% CRJ10DF1201T
XM R803
/
U1B ns
p
00MNM1180G020 CHIP RES. 18OHM/1608/1% CRJ10DF18R0T
XM R804
/
U1B ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
XM R811
/
U1B ns
p
00MNM12200020 CHIP RES. 220 OHM 1% CRJ10DF2200T
XM R812
/
U1B ns
p
00MNM11800020 CHIP RES. 180 OHM 1% CRJ10DF1800T
XM R813
/
U1B ns
p
00MNM11800020 CHIP RES. 180 OHM 1% CRJ10DF1800T
XM X501
/
U1B ns
p
00D2623516908 X'TAL 45.1584 MHZ COX45158ISCR
241
