Marantz SR8001 Service Manual

3
Surround Mode Input Signal Decoding
Output Channel Front information display
L/R C
SL
SR
SBL
SBR
SubW Signal format indicators Channel status
Dolby Virtual
Speaker
Dolby Surr.EX Dolby Virtual Speaker O ----
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Virtual Speaker O ----
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D (2ch) Dolby Virtual Speaker O ----
2 DIGITAL
L, R
Dolby D (2ch Surr) Dolby Virtual Speaker
O ----
2 DIGITAL 2 SURROUND
L, R, S
DTS-ES Dolby Virtual Speaker O - - - - dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 Dolby Virtual Speaker O - - - - dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) Dolby Virtual Speaker O - - - - dts L, C, R, SL, SR, LFE
Multi Ch-PCM Dolby Virtual Speaker O - - - - M-PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) Dolby Virtual Speaker
O - - - - SA-CD L, C, R, SL, SR, LFE
SA-CD (2ch) Dolby Virtual Speaker O ----SA-CD L, R
PCM (Audio) Dolby Virtual Speaker O ----PCM L, R
HDCD Dolby Virtual Speaker O - - - - PCM, HDCD L, R
Analog Dolby Virtual Speaker
O ----ANALOG -
Multi Ch.
Stereo
Dolby Surr.EX Dolby Digital EX OOOOO
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1 OOO - O
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D (2ch) Multi Channel Stereo OOOOO
2 DIGITAL
L, R
Dolby D (2ch Surr) Multi Channel Stereo OOOOO
2 DIGITAL 2 SURROUND
L, R, S
DTS-ES DTS-ES
OOOOO dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS-96/24 OOO - O dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1 OOO - O dts L, C, R, SL, SR, LFE
Multi Ch-PCM Multi Ch-PCM OOO - O M-PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 96kHz Multi Ch-PCM 96kHz OOO - O M-PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) Multi Ch-PCM
OOO - O SA-CD L, C, R, SL, SR, LFE
SA-CD (2ch) Multi Channel Stereo OOOOO SA-CD L, R
PCM (Audio) Multi Channel Stereo OOOOO PCM L, R
HDCD Multi Channel Stereo
OOOOO PCM, HDCD L, R
Analog Multi Channel Stereo
OOOOO ANALOG -
Dolby H.P Dolby Surr.EX Dolby H.P O ----
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby H.P
O ----
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D (2ch) Dolby H.P O ----
2 DIGITAL
L, R
Dolby D (2ch Surr) Dolby H.P O ----
2 DIGITAL 2 SURROUND
L, R, S
DTS-ES Dolby H.P O - - - - dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 Dolby H.P
O - - - - dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) Dolby H.P
O - - - - dts L, C, R, SL, SR, LFE
Multi Ch-PCM Dolby H.P O - - - - M-PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) Dolby H.P O - - - - SA-CD L, C, R, SL, SR, LFE
SA-CD (2ch) Dolby H.P
O ----SA-CD L, R
PCM (Audio) Dolby H.P O ----PCM L, R
HDCD Dolby H.P O - - - - PCM, HDCD L, R
Analog Dolby H.P O ----ANALOG -
THX
(THX Games)
Dolby Surr.EX Dolby Digital + THX Surround EX OOOOO
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1+ THX 5.1
OOO - O
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D (2ch) Pro Logic II x movie + THX
OOOOO
2 DIGITAL
L, R
Dolby D (2ch Surr) Pro Logic II x movie + THX
OOOOO
2 DIGITAL 2 SURROUND
L, R, S
DTS-ES DTS-ES + THX OOOOO dts, ES L, C, R, SL, SR, S, LFE
DTS (5.1ch) DTS + THX 5.1 OOO - O dts L, C, R, SL, SR, LFE
Multi Ch-PCM Multi Ch-PCM + THX5.1
OOO - O M-PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) Multi Ch-PCM + THX5.1
OOO - O SA-CD L, C, R, SL, SR, LFE
SA-CD (2ch) Pro Logic II x movie + THX
OOOOO SA-CD L, R
PCM (Audio) Pro Logic II x movie + THX OOOOO PCM L, R
HDCD Pro Logic II x movie + THX OOOOO PCM, HDCD L, R
Analog Pro Logic II x movie + THX
OOOOO ANALOG -
THX Select2
(THX EX)
(THX Music)
(THX Games)
Dolby Surr.EX Dolby Digital + THX Surround EX
OOOOO
2 DIGITAL EX
L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1+ THX Select2 Cinema OOOOO
2 DIGITAL
L, C, R, SL, SR, LFE
Dolby D (2ch) Pro Logic II x movie + THX
OOOOO
2 DIGITAL
L, R
Dolby D (2ch Surr) Pro Logic II x movie + THX OOOOO
2 DIGITAL 2 SURROUND
L, R, S
DTS-ES DTS-ES + THX
OOOOO dts, ES L, C, R, SL, SR, S, LFE
DTS (5.1ch) DTS + THX Select2 Cinema
OOOOO dts L, C, R, SL, SR, LFE
Multi Ch-PCM Multi Ch-PCM + THX Select2 Cinema OOOOO M-PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) Multi Ch-PCM + THX Select2 Cinema
OOOOO SA-CD L, C, R, SL, SR, LFE
SA-CD (2ch) Pro Logic II x movie + THX
OOOOO SA-CD L, R
PCM (Audio) Pro Logic II x movie + THX
OOOOO PCM L, R
HDCD Pro Logic II x movie + THX
OOOOO PCM, HDCD L, R
Analog Pro Logic II x movie + THX OOOOO ANALOG -
Notes:
• Dolby Digital (2 channel L/R): Speakers for signal
with Dolby Surround are fully equipped.
• No sound is outputs from the surround speaker,
center speaker and subwoofer if the DVD disc has
no surround data.
Abbreviations
L/R : Front speakers
C : Center speaker
SL/SR : Surround speakers
SBL/SBR : Surround back speakers
SubW : Subwoofer
