GENERATOR POWER AND POWER FACTOR (GENERATOR OUTPUT) – This message contains the generator
power factor, average total real power, total reactive power and average apparent power as seen at the output of
the generator, possibly stepped up by potential and current transformers.
Message ID (0xFF10) – Generator Power and Power Factor (Generator Output)
Source: DVR
®
2000E+
Message Group: Control
PDU Format: 255 (PDU2)
PDU Specific: 16
BYTE 0 BYTE 1 BYTE 2 BYTE 3 BYTE 4 BYTE 5 BYTE 6 BYTE 7
Power
Factor
(LSB)
Power
Factor
(MSB)
Real
Power
(LSB)
Real
Power
(MSB)
Apparent
Power
(LSB)
Apparent
Power
(MSB)
Reactive
Power
(LSB)
Reactive
Power
(MSB)
0x?? 0x?? 0x?? 0x?? 0x?? 0x?? 0x?? 0x??
Byte 0 Generator Power Factor (LSB) – this is the Least Significant Byte of the generator
power factor. (1 bit = 0.001 pu)
Byte 1 Generator Power Factor (MSB) – this is the Most Significant Byte of the generator
power factor. (1 bit = 0.001 pu)
Byte 2 Generator Real 3-phase Power (LSB) – this is the Least Significant Byte of the
generator real power. (1 bit = 0.1kW)
Byte 3 Generator Real 3-phase Power (MSB) – this is the Most Significant Byte of the
generator real power. (1 bit = 0.1kW)
Byte 4 Generator Apparent 3-phase Power (LSB) – this is the Least Significant Byte of the
generator total real power. (1 bit = 0.1kVA)
Byte 5 Generator Apparent 3-phase Power (MSB) – this is the Most Significant Byte of the
generator total real power. (1 bit = 0.1kVA)
Byte 6 Generator Reactive 3-phase Power (LSB) – this is the Least Significant Byte of the
generator total real power. (1 bit = 0.1kVAR)
Byte 7 Generator Reactive 3-phase Power (MSB) – this is the Most Significant Byte of the
generator total real power. (1 bit = 0.1kVAR)
