GENERATOR POWER AND POWER FACTOR (REGULATOR SENSING) – This message contains the generator
power factor, average total real power, total reactive power and average apparent power as seen at the regulator
sensing terminals, possibly stepped down by potential and current transformers.
Message ID (0xFF30) – Generator Power and Power Factor (Regulator Sensing)
Source: DVR
®
2000E+
Message Group: Control
PDU Format: 255 (PDU2)
PDU Specific: 48
BYTE 0 BYTE 1 BYTE 2 BYTE 3 BYTE 4 BYTE 5 BYTE 6 BYTE 7
Power
Sense
Unused Real
Power
(LSB)
Real
Power
(MSB)
Apparent
Power
(LSB)
Apparent
Power
(MSB)
Reactive
Power
(LSB)
Reactive
Power
(MSB)
0x?? 0xFF 0x?? 0x?? 0x?? 0x?? 0x?? 0x??
Byte 0 Generator Power Factor Sense – this is the direction of the generator power factor
as given by the following enumeration:
00 – Lagging Power Factor
01 – Leading Power Factor
Byte 1 Unused
Byte 2 Generator Real 3-phase Power (LSB) – this is the Least Significant Byte of the
generator real power. (1 bit = 1 W)
Byte 3 Generator Real 3-phase Power (MSB) – this is the Most Significant Byte of the
generator real power. (1 bit = 1 W)
Byte 4 Generator Apparent 3-phase Power (LSB) – this is the Least Significant Byte of the
generator total real power. (1 bit = 1 VA)
Byte 5 Generator Apparent 3-phase Power (MSB) – this is the Most Significant Byte of the
generator total real power. (1 bit = 1 VA)
Byte 6 Generator Reactive 3-phase Power (LSB) – this is the Least Significant Byte of the
generator total real power. (1 bit = 1 VAR)
Byte 7 Generator Reactive 3-phase Power (MSB) – this is the Most Significant Byte of the
generator total real power. (1 bit = 1 VAR)
