SETPOINTADJUST-thismessagecanbeusedtoadjustthesetpointoftheregulatorinitsvariousregulation
modes.
Message ID: (0xFFA1) Set Point Adjust
Source: ECU1 or ECU2 or ECU3
Message Group: None
PDU Format: 255 (PDU2)
PDU Specific: 161
BYTE 0 BYTE 1 BYTE 2 BYTE 3 BYTE 4 BYTE 5 BYTE 6 BYTE 7
Unused Unused Field
Current
Set Point
(LSB)
Field
Current
Set Point
(MSB)
Voltage
Set Point
(LSB)
Voltage
Set Point
(MSB)
Voltage
Adjust
(LSB)
Voltage
Adjust
(LSB)
0xFF 0xFF 0x?? 0x?? 0x?? 0x?? 0x?? 0x??
Byte 0 Unused
Byte 1 Unused
Byte 2 Field Current Set Point (LSB) – If Regulation Mode is Field Current Regulation, this
value represents the Least Significant Byte of the field current set point from 0.000-
3.000 A. (1 bit = 1mA)
Byte 3 Field Current Set Point (LSB) – If Regulation Mode is Field Current Regulation, this
value represents the Most Significant Byte of the field current set point from 0.000-
3.000 A. (1 bit = 1mA)
Byte 4 Regulator Voltage Set Point (LSB) – If Regulation Mode is Automatic Voltage Regula-
tion (3 or 1), this value represents the Least Significant Byte of the regulator voltage
set point from 100.0-600.0 V. (1 bit = 0.1 V)
Byte 5 Regulator Voltage Set Point (MSB) – If Regulation Mode is Automatic Voltage Regu-
lation (3 or 1), this value represents the Most Significant Byte of the regulator volt-
age set point from 100.0-600.0 V. (1 bit = 0.1 V)
Byte 6 VoltageAdjust(LSB)–IfRegulationModeisAutomaticVoltageRegulation(3or1),
thisvaluerepresentstheLeastSignicantByteofavoltageadjustmentasasigned
quantity(1bit=0.1V).Ifthisvoltageadjustmentexceedsathreshold(+/-30%of
the voltage regulation set point), it will be saturated.
Byte 7 VoltageAdjust(MSB)–IfRegulationModeisAutomaticVoltageRegulation(3or1),
thisvaluerepresentstheMostSignicantByteofavoltageadjustmentasasigned
quantity(1bit=0.1V).Ifthisvoltageadjustmentexceedsathreshold(+/-30%of
the voltage regulation set point), it will be saturated.
