10
2. The unit must be mounted on a at surface in a vertical position with the incoming
and outgoing water pipes facing down. It is not possible to install the unit horizontal-
ly. Please use the installation sticker guide and screws supplied in the product's
original package. Drill the wall for the indicated holes. Check that there are no hidden
wires or pipes, before drilling holes for wall mounting.
3. Secure the bracket to the wall with the screws supplied.
5. There are two cable entry points. You can choose one of them and the back plate
will have to be cut out.
6. It is essential that this appliance is connected to a ground.
PLUMBING
7. Use stainless steel exible hose or copper tubing of ½" on the inlet and outlet
pipes.
4. Hook the unit and screw the xing holes, placing special attention to the bottom
