QUICK START GUIDE
1. Securely mount your water heater in an appropriate
location using the hanging bracket and wall anchors supplied
with the unit.
PP110: the unit should not
be
installed more than 6ft
PP220 (PPXE5): the unit
should not be installed
more than 40ft away from
2. Secure the bracket to the walI with the screws supplied.
WARNING: Working with electricity can be dangerous. If you are not
knowledgeable about basic electrical practices and local building codes
please DO NOT attempt to install this unit without the assistance of a
3. The units have to be installed in copper pipe and for the
connection between the pipe and the heater use exible
110V (PP110): Connect (1) white wire to the single pole (110V) breaker. Connect (1) white wire to the
neutral bar on your breaker box. It does not matter which white wire is connected to power and which is
connected to neutral. Connect the green ground wire to the ground bar on your breaker box.
220V (PPXE5): Connect (2) white wires to the double pole (220V) breaker. Connect the green ground wire
to the ground bar on your breaker box.
Caution: these are TWO separate units. Not one unit that can be wired as 11OV OR 220V. Please check the
model number on the right side of your unit.
4. Make the electrical connections to the breaker. Breaker
size can be 10, 20, 30, or 40 AMPS, depending on the
amount of heating needed (Power setting cannot exceed
breaker size). Wire gauge will vary depending on amper-
age and distance. Contact an electrician if you're not sure.
6. Turn on the hot water faucet and adjust the heater to the
appropriate ow and temperature setting for your situa-
tion.
Use caution not to get scalded until the appropriate
temperature settings are in place. Higher ow rates will
result in cooler water and vice versa. Higher amperage will
DO NOT TURN ON THE BREAKER YET!
5. Turn on the hot water faucet and allow it to ow for at
least 30 seconds. Turn the faucet back o. Turn on the
When you turn on the tap, the water heater will automatically engage. When you turn o the tap, the water
heater will turn o automatically.
Enjoy endless, energy ecient hot water for years to come!
Disclaimer: This document is intended as a quick reference only and does not contain all of the important
safety warnings and other information necessary to safely operate your heater. For a complete list of safety
warnings and instructions please reference the instruction manual before operating your water heater.
