FOR PP110:
Connect (1) white wire to the single pole 10, 20, 30 or 40 Amp circuit breaker.
Connect (1) white wire to the neutral bar on your breaker box. It does not matter
which white wire connects to neutral and which connects to the breaker. Connect the
green ground wire to the ground bar on your breaker box.
FOR PP220 (PPXE5):
Connect the (2) white wires to the double pole 10, 20, 30 or 40 Amp circuit breaker.
Connect the green ground wire to the ground bar on your breaker box.
This appliance MUST be grounded. Connect the ground wire, as indicated in the
Electrical Code.
When all connections are satisfactorily prepared, install the heater cover. With the
insulated container o and water ow modier (optional) fully open, the faucet must
be opened fully to get maximum water ow. It is necessary to ensure that the water
tank is full before turning the power on. This is an essential step to protect the heating
element.
Note that the above instructions are simply guidelines that apply to most installations.
The size of the switch and wire gauge must meet all local, state, provincial and nation-
al electrical codes in your area. Contact an electrician if you're not sure.
To determine the minimum electrical circuit please see the next table:
06
The heater must be connected to its own independent electrical circuit. InstalI a fuse
box or switch ("breaker") for exclusive use of the heater.
The wire gauge necessary will vary based on amperage and distance to the breaker,
but 8 gauge wire is generally sucient for most installations. If the distance is very
short, sometimes smaller gauge wire may be used. If you aren't sure which gauge of
wire should be used, contact an electrician. The supply wire, main switch and circuit
protection (Leakage Circuit Breaker) must be sucient for the amperage required.
Please check the table above and the ow rate/temperature rise chart for the appro-
priate amperage for your situation. Note that the lower the amperage, the lower the
water temperature rise will be.
DO NOT TURN ON THE BREAKER SWITCH UNTIL ALL ELECTRICAL AND PLUMBING
ELECTRICAL REQUIREMENTS
