Product Description
3.5.1 Grinding speed knob
The grinding speed knob sets the speed of the grinding wheel. The speed can be set to different speeds to grind 0
mm to 4 mm of the cutting teeth. At low speed, grinding is done in a pulsing motion.
3.6 Chain overview
This section describes the definitions for the parts of a normal chain.
Pos Part Description
A Cutters R: Right cutter. L: Left cutter.
B Drive link
The lower part of a link. Used to push the chain forward in the
chainsaw, etc.
C Tie strap The links separating the cutters.
D Cutting tooth The part of the cutter that cuts chain.
E Gullet The space between the cutting tooth and the depth gauge.
F Rivet hole A hole where the rivet is placed.
G Depth gauge The front part of the cutter.
B
C
F
D
G
E
A
R L
A
