Grindomatic
12 Grindomatic 201708 EN
Product Description
3.7 Technical data
Parameter Value
Supply voltage 12-15 V DC
Power 144 W
Current 12 A
Over-current protection Automatic fuse type ptc
Rotation speed 3250 rpm
Peripheral speed 25 m/s
Grinding wheel dimensions
(for the grinding wheels included in the
delivery)
Outer diameter (OD) × Width (W) × Inner diameter (ID):
• 150mm x 3.2mm x 16mm (5 7/8” x 1/8” x 5/8”)
• 150mm x 4.8mm x 16mm (5 7/8” x 3/16” x 5/8”)
• 150mm x 6.4mm x 16mm (5 7/8” x 1/4” x 5/8”)
Max dimensions for the
Grindomatic Auto Chain Grinder
Length (L) x Width (W) x Height (H):
400mm x 350mm x 350mm (15.7” x 13.8” x 13.8”)
Weight of the machine 11.5kg
Compressed air supply pressure 5-8 bar
