3.4 Grinding head
The grinding wheel on the grinding head sharpens the chains. The type of wheel, the top-plate angles, the settings of
the grinding head, and the profiling of the grinding wheel all determine how the chain is sharpened.
D
C
B
A
Pos Part Description
A Grinding wheel Grinds the chain.
B Grinding wheel nut Keeps the grinding wheel in place.
C Grinding wheel guard Protects the user and grinding wheel when the chain is sharpened.
D 2 screws Secures the grinding wheel guard in place.
