Markusson Grindomatic V12 - Stand Assembly; Stand Assembly Steps

Grindomatic
Grindomatic 201708 EN 37
Assembling the stand
9 Assembling the stand
CAUTION The Grindomatic Auto Chain Grinder machine must always be safely attached to the stand. Make
sure that it is safely attached.
1. To mount the grinder on the stand, begin by assembling the stand.
2. The stand comes in 4 pieces: two sides, one base and one front piece.
A
2x
B
1x
C
1x
D
2x
E
2x
I
2x
F
3x
J
7x
G
12x
K
3x
H
4x
L
2x
