Marshall Electronics CV610-U3-V2 - Extension Module Diagram

CV610-U3-V2 Manual
www.marshall-usa.com 8
1. Extension Port (Connect to the camera body)
2. Audio line in (3.5mm jack)
3. RS232 Port
4. CVBS (Inactive)
5. RS422/485 Port
6. HDMI Video Output Port
4.3 Extension Module
1
3
2
5
4
6
1. Extension Port (Connect to the camera body)
2. Audio line in (3.5mm jack)
3. RS232 Port
4. CVBS (Inactive)
5. RS422/485 Port
6. HDMI Video Output Port
