7.1 EXPOSURE Menu
The EXPOSURE menu is used to set the items related to
exposure.
MODE (Exposure Mode)
FULL AUTO: The exposure is adjusted automatically
using the sensitivity, electronic shutter speed, and iris.
BRIGHT: Adjust the brightness level (LEVEL:0~27) manually.
SHUTTER PRI: Shutter Priority mode. The exposure is adjusted automatically using the
sensitivity and iris. Adjust the electronic shutter speed (SPEED) manually.
IRIS PRI: Iris Priority mode. The exposure is adjusted automatically using the sensitivity and
electronic shutter speed. Adjust the iris (IRIS) manually.
MANUAL: Adjust the sensitivity (GAIN), electronic shutter speed (SPEED) and iris (IRIS) manually.
When you select one from various exposure modes, some of the following setting items that are
required for the selected mode appear.
GAIN: Select the gain from the following:
0, 2, 4, 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26, 28 dB
SPEED: Select the electronic shutter speed from the following:
When video format is set to 1080P50, 1080P25, 720P50, Speed can be selected from the
following:
1/1, 1/2, 1/3, 1/6, 1/12, 1/25, 1/50, 1/75, 1/100, 1/120, 1/150, 1/215, 1/300, 1/425, 1/600, 1/1000,
1/1250, 1/1750, 1/2500, 1/3500, 1/6000, 1/10K.
When video format is set to 1080P30, 1080P60, 720P60, Speed can be selected from the
following:
1/1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/60, 1/90, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/725, 1/1000,
1/1500, 1/2000, 1/3000, 1/4000, 1/6000, 1/10K.
IRIS: Select the iris the following: CLOSE, F14, F11, F9.6, F8.0, F6.8, F5.6, F4.8, F4.0, F3.4, F2.8,
F2.4, F2.0, F1.6
LEVEL: Select the brightness level from 0 to 27.
