For these commands, the detailed command descriptions in section 10 show a
check mark beside RS-232, but no check mark beside IEEE-488.
Table 6 - Commands for RS-232 Only
IEEE-488 Message RS-232 Equivalent
GTL LOCAL command
GTR REMOTE command
LLO LOCKOUT command
i) Commands for IEEE-488
These are all of the commands except for those used for RS-232 only, as
described above. All commands are transferred over the IEEE-488 as data,
except for the commands LOCAL, REMOTE, and LOCKOUT, which are
implemented per the IEEE Standards as uniline messages.
The detailed command descriptions in section 10 show a check mark T beside
IEEE-488 for these commands.
9.6.2 Command Syntax
The following syntax rules apply to all of the remote commands. Information about the
syntax of response messages is also given.
a) Parameter Syntax Rules
Table 7 lists the units accepted in command parameters and used in
responses. All commands and units may be entered in upper or lower case.
Table 7 - Units Accepted in Parameters and Used in Responses
Units Meaning
uV Volts in units of microvolts1
mV Volts in units of millivolts1
V Volts in units of volts
kV Volts in units of kilovolts1
uA Current in units of microamperes1
mA Current in units of milliamps1
A Current in units of amps
Ohm Resistance in units of ohms
kOhm Resistance in units of kilohms1
MOhm Resistance in units of megohms1
cel Temperature in degrees Celsius
far Temperature in degrees Fahrenheit
psi Pressure in pounds per square inch
mmHg Pressure in millimeters of mercury at 0 °C
inHg Pressure in inches of mercury at 0 °C
