CDD USER GUIDE
CDD User Guide V1.0 17
CHOOSING A MOUNTING LOCATION
CDD Series loudspeakers should be mounted above head height – high enough to clear peoples’ heads for clean coverage but
low enough to avoid over-exciting room resonances.
Tilt angles should be set so that the loudspeaker’s maximum output (usually on-axis of the loudspeaker centre) is aimed at the
furthest listener across the room.
The horizontal dispersion of CDD Series speakers produces a square coverage pattern and therefore to maximise efficiency of
coverage we recommend mounting speakers as below.
NOTE: CDD Series speakers are NOT designed to be placed adjacent to one another as there is likely to be an overlap in horizontal
coverage in part of the intended area which could lead to unwanted comb filtering.
EASE data
To assist system design and speaker placement within a venue, high-resolution GLL files for CDD Series models may be
downloaded from the Martin Audio website: www.martin-audio.com
