CDD USER GUIDE
CDD User Guide V1.0 14
GRILLE REMOVAL AND REPLACEMENT
Grilles on CDD Series cabinets are designed to be easy to remove to facilitate driver rotation. No screws are used to hold them
in place; they are manufactured with a natural spring which holds them in place in slots in each side of the cabinets. The grilles
have two or three gaps in the sides into which an appropriately-sized flat-bladed screwdriver can be inserted to assist in removal.
Insert the screwdriver blade into one of the gaps - either at the top or bottom of the cabinet (don’t start in the middle).
