CDD USER GUIDE
CDD User Guide V1.0 51
CDD10, CDD12, CDD15
Compact, Coaxial Differential Dispersion
passive two-way system
Compact, high-output, Coaxial Differential
Dispersion passive two-way system
High-output, Coaxial Differential
Dispersion passive two-way system
65Hz – 20kHz + 3dB, -10dB @ 55Hz
62Hz – 20kHz + 3dB, -10dB @ 50Hz
55Hz – 20kHz + 3dB, -10dB @ 45Hz
LF: 10” (250 mm)/2.5” (63.5 mm) voice
coil, long excursion, shared ferrite motor
system with HF
HF: 1” (25 mm) exit/1.4” (38 mm) voice
coil, polyimide dome compression driver
LF: 12” (300 mm)/2.5” (63.5 mm) voice
coil, long excursion, shared ferrite motor
system with HF
HF: 1” (25 mm) exit/1.7” (44 mm) voice
coil, polyimide dome compression driver
LF: 15” (380 mm)/3” (75 mm) voice coil,
long excursion, shared ferrite motor
system with HF
HF: 1.4” (32 mm) exit/3” (75 mm) voice
coil, titanium dome compression driver
120 dB continuous, 126 dB peak
122 dB continuous, 128 dB peak
126 dB continuous, 132 dB peak
110˚-70˚ horizontal, 60˚ vertical (user-
rotatable)
110˚-60˚ horizontal, 60˚ vertical (user-
rotatable)
110˚-60˚ horizontal, 60˚ vertical (user-
rotatable)
38 litre, composite material
68 litre, composite material
Black or white textured paint
Black or white textured paint
Black or white textured paint
Standard models only: black or white
perforated steel with scrim cloth backing
“WR” models only: black or white
perforated, zinc-plated steel with scrim
cloth backing, Declon® synthetic fabric
layer and inner, zinc-plated, hydrophobic
steel mesh layer
Standard models only: black or white
perforated steel with scrim cloth backing
“WR” models only: black or white
perforated, zinc-plated steel with scrim
cloth backing, Declon® synthetic fabric
layer and inner, zinc-plated, hydrophobic
steel mesh layer
Standard models only: black or white
perforated steel with scrim cloth backing
“WR” models only: black or white
perforated, zinc-plated steel with scrim
cloth backing, Declon® synthetic fabric
layer and inner, zinc-plated, hydrophobic
steel mesh layer
Low-profile 20 A push-lock
WR models only: weatherproof cover
with gasket seal and cable gland
Low-profile 20 A push-lock
WR models only: weatherproof cover with
gasket seal and cable gland
Low-profile 20 A push-lock
WR models only: weatherproof cover with
gasket seal and cable gland
Left to right: Input+, Input -, Link -, Link +
Left to right: Input+, Input -, Link -, Link +
Left to right: Input+, Input -, Link -, Link +
6 x M8 inserts for wall bracket
10 x M8 fly points
6 x M8 inserts for wall bracket
10 x M8 fly points
IP54 (Model CDD10-WR only)
IP54 (Model CDD12-WR only)
IP54 (Model CDD15-WR only)
(W) 323 mm x (H) 515 mm x (D) 311 mm
(W) 12.7 in x (H) 20.3 in x (D) 12.2 in
(W) 357 mm x (H) 571 mm x (D) 348 mm
(W) 14.1 in x (H) 22.5 in x (D) 13.7 in
(W) 425 mm x (H) 691 mm x (D) 411 mm
(W) 16.7 in x (H) 27.2 in x (D) 16.2 in
WB10/12B wall bracket black
WB10/12W wall bracket white
CDDYA10B yoke assembly black
CDDYA10W yoke assembly white
CDDWB10/12B wall bracket black
CDDWB10/12W wall bracket white
CDDYA12B yoke assembly black
CDDYA12W yoke assembly white
CDDYA15B yoke assembly black
CDDYA15W yoke assembly white
Notes
(1) Measured on-axis in open (4pi) space at 2 metres, then referred to 1 metre.
(2) AES Standard ANSI S4.26-1984.
(3) Measured in open (4pi) space at 2 metres with 2.83V input, using band limited pink noise, then referred to 1 metre.
(4) Calculated at 1 m.
(5) Measured in open (4pi) space at 2 metres.
