CDD USER GUIDE
CDD User Guide V1.0 52
CSX112-F, CSX212-F
Compact, single driver, direct radiating subwoofer
Compact, dual-driver, direct radiating subwoofer
48Hz – 150Hz + 3dB, -10dB @ 35Hz
48Hz – 150Hz + 3dB, -10dB @ 35Hz
12” (300 mm)/3” (75 mm) voice coil, long excursion,
ferrite magnet, waterproof cone
2 x 12” (300 mm)/3” (75 mm) voice coil, long excursion,
ferrite magnet, waterproof cone
128 dB continuous, 134 dB peak
134 dB continuous, 140 dB peak
80–120 Hz, via DX0.5 or DX4.0 controller
80–120 Hz, via DX0.5 or DX4.0 controller
52 litre, high-density MDF
100 litre, high-density MDF
Black or white textured paint
Black or white textured paint
Black or white perforated steel
Black or white perforated steel
Low-profile 20 A push-lock
WR models only: weatherproof cover with gasket seal and
cable gland
Low-profile 20 A push-lock
WR models only: weatherproof cover with gasket seal and
cable gland
Left to right: Input+, Input -, Link -, Link +
Left to right: Input+, Input -, Link -, Link +
IP24 (Model CSX112-FWR only)
IP24 (Model CSX212-FWR only)
(W) 487 mm x (H) 385 mm x (D) 410 mm
(W) 19.2 in x (H) 15.2 in x (D) 16.1 in
((W) 872 mm x (H) 385 mm x (D) 437 mm
(W) 34.3 in x (H) 15.2 in x (D) 17.2 in
Notes
(1) Measured on-axis in half space at 2 metres, then referred to 1 metre.
(2) AES Standard ANSI S4.26-1984.
(3) Measured in half space at 2 metres with 2.83V input, using band limited pink noise, then referred to 1 metre.
(4) Calculated in half space at 1 metre.
