CDD USER GUIDE
CDD User Guide V1.0 53
CSX118-F, CSX218-F
Compact, single driver, direct radiating subwoofer
Compact, dual-driver, direct radiating subwoofer
40Hz – 150Hz + 3dB, -10dB @ 35Hz
35Hz – 150Hz + 3dB, -10dB @ 35Hz
18” (460 mm)/4” (100 mm) voice coil, long excursion,
ferrite magnet, waterproof cone
2 x 18” (460 mm)/4” (100 mm) voice coil, long excursion,
ferrite magnet, waterproof cone
132dB continuous, 138 dB peak
138 dB continuous, 144 dB peak
80–120 Hz, via DX0.5 or DX4.0 controller
80–120 Hz, via DX0.5 or DX4.0 controller
160 litre, high-density MDF
330 litre high-density MDF
Black or white textured paint
Black or white textured paint
Black or white perforated steel
Black or white perforated steel
Low-profile 20 A push-lock
WR models only: weatherproof cover with gasket seal and
cable gland
Low-profile 20 A push-lock
WR models only: weatherproof cover with gasket seal and
cable gland
Left to right: Input+, Input -, Link -, Link +
Left to right: Input+, Input -, Link -, Link +
IP24 (Model CSX118F-WR only)
IP24 (Model CSX218F-WR only)
(W) 530 mm x (H) 662 mm x (D) 640 mm
(W) 20.9 in x (H) 26.1 in x (D) 25.2 in
(W) 1085 mm x (H) 530 mm x (D) 780 mm*
(W) 42.7 in x (H) 20.9 in x (D) 30.7 in*
*905 mm (35.6 in) with wheels
Notes
(1) Measured on-axis in half space at 2 metres, then referred to 1 metre.
(2) AES Standard ANSI S4.26-1984.
(3) Measured in half space at 2 metres with 2.83V input, using band limited pink noise, then referred to 1 metre.
(4) Calculated in half space at 1 metre.
