CDD USER GUIDE
CDD User Guide V1.0 7
…………
THE CDD RANGE
The CDD range consists of six full-range systems and four sub-woofers (the CSX Series), as summarised below. Please refer to
“Specifications” on page 48 for full technical specifications for each model (DX0.5 System controller also shown).
Full-range systems:
Model
LF driver
HF driver
LF -3dB point
Power rating
A
CDD5*
5” (125 mm)
0.7” (19 mm)
100 Hz
100 W
B
CDD6*
6.5” (165 mm)
1” (25 mm)
80 Hz
150 W
C
CDD8
8” (200 mm)
1” (25 mm)
70 Hz
200 W
D
CDD10
10” (250 mm)
1” (25 mm)
65 Hz
250 W
E
CDD12
12” (300 mm)
1” (25 mm)
62 Hz
300 W
F
CDD15
15” (380 mm)
1.4“ (35 mm)
55 Hz
400 W
* Model CDD5TX and CDD6TX (70/100 V-line version) also available
Subwoofers:
Model
LF driver (dia.)
LF -3 dB point
Power rating
G
CSX112
1 x 12” (250 mm)
48 Hz
400 W
H
CSX212
2 x 12” (250 mm)
48 Hz
800 W
I
CSX118
1 x 18” (460 mm)
40 Hz
1000 W
J
CSX218
2 x 18” (460 mm)
35 Hz
2000 W
Colour coding - all CDD and CSX models are available in:
– white – suffix ‘W’ is added to model number
– black – suffix ‘B’ is added to model number
– custom RAL colour – suffix ‘RAL’ is added to model number
All CSX models may be ordered with flying points pre-fitted; add ‘–F’ to model number.
A
B
C
F
D
H
G
I
E
J
