CDD USER GUIDE
CDD User Guide V1.0 50
SPECIFICATIONS
CDD5, CDD6, CDD8
Ultra-compact, Coaxial Differential
Dispersion passive two-way system
Ultra-compact, Coaxial Differential
Dispersion passive two-way system
Ultra-compact, Coaxial Differential
Dispersion passive two-way system
100Hz – 20kHz + 3dB, -10dB @ 70Hz
80Hz – 20kHz + 3dB, -10dB @ 70Hz
70Hz – 20kHz + 3dB, -10dB @ 70Hz
LF: 5.25” (130 mm)/1.25” (32 mm) voice
coil, long excursion, ferrite motor
system
HF: 0.75” (19 mm) voice coil, fabric
dome with neodymium motor system
LF: 6.5” (165 mm)/1.5” (38 mm) voice
coil, long excursion, ferrite motor system
HF: 1” (25 mm) voice coil, fabric dome
with neodymium motor system
LF: 8” (200 mm)/2” (50 mm) voice coil,
long excursion, shared ferrite motor
system with HF
HF: 1” (25 mm) exit/1.4” (38 mm) voice
coil, polyimide dome compression driver
MA2.0, MA3.0
VIA2502, VIA2004
MA2.8Q, MA2.0
VIA2502, VIA2004
110 dB continuous, 116 dB peak
113 dB continuous, 119 dB peak
117 dB continuous, 123 dB peak
120˚-90˚ horizontal, 80˚ vertical (user-
rotatable)
110˚-80˚ horizontal, 80˚ vertical (user-
rotatable)
110˚-80˚ horizontal, 60˚ vertical (user-
rotatable)
9 litre, composite material
14 litre, composite material
Black or white textured paint
Black or white textured paint
Standard models only: black or white
perforated steel with scrim cloth backing
“WR” models only: black or white
perforated, zinc-plated steel with scrim
cloth backing, Declon® synthetic fabric
layer and inner, zinc-plated, hydrophobic
steel mesh layer
Standard models only: black or white
perforated steel with scrim cloth backing
“WR” models only: black or white
perforated, zinc-plated steel with scrim
cloth backing, Declon® synthetic fabric
layer and inner, zinc-plated, hydrophobic
steel mesh layer
Standard models only: black or white
perforated steel with scrim cloth backing
“WR” models only: black or white
perforated, zinc-plated steel with scrim
cloth backing, Declon® synthetic fabric
layer and inner, zinc-plated, hydrophobic
steel mesh layer
Low-profile 13 A push-lock
WR models only: weatherproof cover
with gasket seal and cable gland
Low-profile 13 A push-lock
WR models only: weatherproof cover with
gasket seal and cable gland
Low-profile 13 A push-lock
WR models only: weatherproof cover with
gasket seal and cable gland
Left to right: Input+, Input -, Link -, Link +
Left to right: Input+, Input -, Link -, Link +
Left to right: Input+, Input -, Link -, Link +
6 x M5 inserts for wall/ceiling brackets
4 x M6 inserts for wall/ceiling brackets
6 x M6 inserts for wall/ceiling brackets
IP54 (Model CDD5TX-WR only)
IP54 (Model CDD6TX-WR only)
IP54 (Model CDD8-WR only)
(W) 160 mm x (H) 230 mm x (D) 149 mm
(W) 6.3 in x (H) 9.1 in x (D) 5.9 in
(W) 210 mm x (H) 325 mm x (D) 210 mm
(W) 8.3 in x (H) 12.8 in x (D) 8.3 in
(W) 256 mm x (H) 410 mm x (D) 253 mm
(W) 10.1 in x (H) 16.1 in x (D) 10 in
CDDCB5B ceiling bracket black
CDDCB5W ceiling bracket white
WB6/8B wall bracket black
WB6/8W wall bracket white
CDDCB6/8B ceiling bracket black
CDDCB6/8W ceiling bracket white
WB6/8B wall bracket black
WB6/8W wall bracket white
CDDCB6/8B ceiling bracket black
CDDCB6/8W ceiling bracket white
Notes
(1) Measured on-axis in open (4pi) space at 2 metres, then referred to 1 metre.
(2) AES Standard ANSI S4.26-1984.
(3) Measured in open (4pi) space at 2 metres with 2.83V input, using band limited pink noise, then referred to 1 metre.
(4) Calculated at 1 m.
(5) Measured in open (4pi) space at 2 metres.
