Message Appears when... What to do
RST (Reset) ... the fixture is indexing effects at startup. Wait for reset to complete.
SRST (Serial reset)
... the fixture has received a reset command
from the controller.
Wait for reset to complete. Set
PERS/dRES to off to prevent accidental
reset commands.
HOME
... the effects have been indexed and are
moving to their default positions.
Wait a few moments.
OPEN
...the lamp access cover is not fully closed.
Verify that the lamp access cover is locked
in place.
LERR (Lamp error)
... the lamp doesn’t ignite within 10 minutes of
receiving the ‘Lamp ON’ command. Likely
reasons are a missing or defective lamp, or
insufficient AC voltage.
Check the lamp. Check that the voltage
and frequency settings match the local
supply.
MERR (Memory error) ...the EEPROM memory cannot be read.
Contact Martin service personnel for
assistance.
ShER (Short error)
... the fixture detects the lamp is ON but no
‘Lamp ON’ command has been received. This
can occur if the lamp relay is stuck or if the
lamp-power feedback circuit fails. The fixture
may be operated but remote lamp on/off may
be effected.
Contact Martin service personnel for
assistance.
bTER (Base temperature error)
HTER (Head temperature error)
... there is a fault with the temperature sensor
in the base or head.
Contact Martin service personnel for
assistance.
FbEP (Feedback error pan)
FbET (Feedback error tilt)
FbER (Feedback error pan/tilt)
...pan (FbEp), tilt (FbET) or both (FbER)
feedback circuits are malfunctioning. It will still
be possible to operate the fixture, though it
goes into a “safe” mode where maximum
speed is reduced, thus preventing the fixture
from losing track of its home position (losing
step).
Contact Martin service personnel for
assistance.
PAER (Pan time-out)
TIER (Tilt time-out)
CYER (Cyan time-out)
MAER (Magenta time-out)
YEER (Yellow time-out)
CTER (CTC time-out)
FOER (Focus time-out)
ZOER (Zoom time-out)
...the electric indexing circuit is
malfunctioning. The fixture will, after the
time-out, establish a mechanical stop, and
continue to work normally.
Reset fixture again. Contact Martin
service personnel if problem continues.
COER (Color wheel time-out)
g1ER (Gobo wheel 1 time-out)
R1ER (Gobo wh. 1 index time-out)
g2ER (Gobo wheel 2 time-out)
R2ER (Gobo wh. 2 index time-out)
EFER (Effect wheel time-out)
REER (Effect wheel index time-out)
...the magnetic-indexing circuit malfunctions
(e.g. sensor defective or magnet missing).
After the time-out, the effect in question stops
in a random position.
Reset fixture again. Contact Martin
service personnel if problem continues.
S3SC (Gobo wh. sensor short)
S4SC (Gobo rot. sensor short)
S5SC (Effect wh. sensor or
zoom/focus switch short)
S6SC (Color wh. or effect rot.
sensor short)
S7SC (Yellow or CTC switch short)
S8SC (Cyan or magenta switch
short)
...an effect does not move away from the index
position under reset, a sensor or micro-switch
circuit is shorted, or a micro-switch is stuck or
connected incorrectly.
Contact Martin service personnel for
assistance.
Table 6: Display messages
