6 MAC 2000 Profile II
Double flight case
Unpacking
1 Open the flight case and pull the drawer all the way out.
2 Release the head (tilt) transport lock.
3 Install rigging hardware as described on page 12.
4 With one person on each side, lift the fixture out of the flight
case.
Packing
1 Disconnect the fixture from power and allow it to cool.
2 Turn the yoke parallel to the sides of the base with the tilt
lock closest to the back.
3 Pull the transport drawer all the way out. With one person
on each side, place the fixture on the drawer with the arrow
pointing in.
4 Remove and stow rigging hardware. Coil and stow the
power cord in the door.
5 Tilt the head so that the lens points away from the door as
shown in Figure 3. Lock the head in the horizontal position.
Do not lock the yoke.
6 Slide the drawer all the way in without forcing. Close the flight case.
Setup for flight case testing
The double flight case has two slide-out arms from which the fixture can hang for testing and setting. Though
unnecessary, the pan and tilt reset can be cancelled by pressing [Menu] and [Enter] at the same time.
1 Open the flight case and pull the drawer all the way out. Release the transport locks.
2 Pull the test arms all out. Tilt the fixture up and over the slide arms so that the handle cross-braces that are
second from the back rest on the arms. The fixture should rest at an angle.
3 Push the transport drawer into the flight case.
Figure 3: Double unit transport position
FRONT
