Control panel menus 29
* Menus marked * are available only when the fixture is connected to mains power. All other menus are available in mains- and
battery-powered operation.
MANUAL
CONTROL*
(continued)
FOCUS 0 - 255 Set focus
FOCUS FINE 0 - 255 Set focus, fine (LSB, default = 128)
PAN 0 - 255 Set pan angle (default = 128)
PAN FINE 0 - 255 Set pan angle, fine (LSB, default = 128)
TILT 0 - 255 Set tilt angle (default = 128)
TILT FINE 0 - 255 Set tilt angle, fine (LSB, default = 128)
SERVICE
ERROR LIST Empty or up to 20 errors Display any errors in memory
FAN CLEAN ON/OFF Activate fan cleaning
PT FEEDBACK
ON
Enable pan/tilt position feedback
systems
OFF Disable pan/tilt position feedback
ADJUST
DIMMER
ADJUSTED/
NOT ADJUSTED
Important! For use by authorized
service technicians during mechanical
adjustment only. Do not enter the
ADJUST menu without Martin™ service
documentation, or you may make the
fixture impossible to use correctly.
Jog wheel must be held in for 5 seconds to
enter.
FROST
NOT ADJUSTED/
1 - 255
FRAMING
ADJUST
RESET/FRAMING
BLADE 1
LEFT...FRAMING
BLADE 4 RIGHT
CALIBRATION
PT AT END STOP ACTION
Calibrate pan/tilt sensor by turning pan
clockwise against end stop, and tilt against
end stop pointing away from display, then
push ACTION
DIMMER ... TILT
Set individual effects to calibration
positions (approx. +/- 5% offset available)
LOAD DEFAULTS Load factory default calibration settings
SAVE DEFAULTS
Replace factory default calibration settings
with current calibration settings
FIRMWARE
UPDATE
NO DEVICE
No USB device present or no firmware on
USB device
UPDATING FILES
Fixture updating internal memory from
USB device
AVAILABLE
FIRMWARE
PERFORMANCE
1.0.0
...
PERFORMANCE
X.X.X
Select firmware from versions stored in
internal memory. Select version, then click
on jog wheel and confirm your choice to
update
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Notes (Default settings in bold print)
Table 2: Control menus
