28 MAC Viper Performance User Guide
DMX LIVE*
RATE 0 - 44 HZ
DMX transmission speed in packets per
second
QUALITY 0 - 100% Percent of packets received
START CODE 0 - 255 Value of the DMX start code
STROBE/SHUTTER ...
Value received on each DMX channel
(values for fine control channels can only
be viewed if available in the DMX mode
the fixture is set to)
TEST*
TEST ALL
Run test sequence of all functions. Press
Escape button to stop test
TEST PAN/TILT
Run test sequence of pan and tilt
functions. Press Escape button to stop test
TEST EFFECTS
Run test sequence of all effects. Press
Escape button to stop test
MANUAL
CONTROL*
RESET RESET Click jog wheel to reset fixture
LAMP ON/OFF Manually strike/douse lamp
STROBE/
SHUTTER
0 - 255 Set shutter/strobe effect (default = 30)
DIMMER 0 - 255 Set dimmer opening
DIMMER FINE 0 - 255 Set dimmer opening, fine (LSB)
CYAN 0 - 255 Add cyan
MAGENTA 0 - 255 Add magenta
YELLOW 0 - 255 Add yellow
CTC 0 - 255
Adjust color temperature control (add
warmth)
COLOR WHEEL 0 - 255 Select color filter
GOBO W 1 SEL 0 - 255 Select gobo
GOBO W 1 I/R 0 - 255 Adjust gobo indexing/rotation
GOBO W 1 I/R
FINE
0 - 255 Adjust gobo indexing/rotation, fine (LSB)
ANIMATION FUNC 0 - 255
Select animation wheel function (indexing
or rotation)
ANIMATION
WHEEL
0 - 255
Set animation wheel indexed angle or
rotation speed
FRAMING 1 POS 0 - 255 Framing blade 1 insertion
FRAMING 1
ANGLE
0 - 255 Framing blade 1 angle
FRAMING 2 POS 0 - 255 Framing blade 2 insertion
FRAMING 2
ANGLE
0 - 255 Framing blade 2 angle
FRAMING 3 POS 0 - 255 Framing blade 3 insertion
FRAMING 3
ANGLE
0 - 255 Framing blade 3 angle
FRAMING 4 POS 0 - 255 Framing blade 4 insertion
FRAMING 4
ANGLE
0 - 255 Framing blade 4 angle
FRAMING
ROTATION
0 - 255
Framing system indexing - rotation to
+/- 55° (default = 128)
FROST 0 - 255 Frost insertion
PRISM I/R 0 - 255 Set prism indexing/rotation
PRISM INX 0 - 255 Set prism indexed position
IRIS 0 - 255 Set iris aperture
ZOOM 0 - 255 Set zoom (default = 128)
ZOOM FINE 0 - 255 Set zoom, fine (LSB, default = 128)
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Notes (Default settings in bold print)
Table 2: Control menus
